APEM Panel Mount Toggle Switch On-Off-On SPDT Screw Terminal 15A 250V AC 639H/X2330

Free Delivery in India | Lowest Global Shipping Charges

APEM Panel Mount Toggle Switch On-Off-On SPDT Screw Terminal 15A 250V AC 639H/X2330

Name: APEM Panel Mount Toggle Switch On-Off-On SPDT Screw Terminal 15A 250V AC 639H/X2330
Brand: APEM
SKU: 206512
Price: 20.22 USD
Availability: InStock



Category Toggle Switch Brand APEM Condition New

Specifications

Country of Origin	France
Brand	APEM
Model	639H/X2330
Mount Type	Panel
Construction	Terminal and contact support are manufactured from a single piece of metal. The contacts are resistance-welded to the terminal for increased mechanical strength
Maximum Operating Temperature	55°C
Contact Configuration	SPDT
Switch Configuration	On-Off-On
Rating	These switches are suitable for motor loads and power applications up to 15A 250VAC or 10A 400VAC
Minimum Operating Temperature	-20°C
Panel Cutout Size	12.2 mm
Terminal type	Screw
Standards/Approvals	UL, NF-VDE EN 61058-1, CSA
Switch Operation	On-Off-On
Actuator Length	17.5mm
Switch Contact Current	15A
Mechanical Life	10000Cycles
Contact AC Voltage	250V ac
Actuator Material	Brass

Key Features

Operates with SPDT contact configuration providing On-Off-On switch operation.
Rated for 15A current at 250V AC suitable for motor loads and power applications.
Panel mount design with a 12.2 mm cutout size and screw terminal connections.
Actuator made of durable brass with a length of 17.5 mm.
Compliance with UL, NF-VDE EN 61058-1, and CSA standards assures quality and safety.
Mechanical life of 10,000 cycles ensures long-lasting performance.
Operates reliably within temperature range from -20°C to 55°C.
Non-illuminated switch suitable for industrial panel installations.

Product Description

APEM 639H/X2330 Panel Mount Toggle Switch is a high-quality SPDT switch designed for industrial and commercial electrical applications that require precise On-Off-On control functionality. It supports motor loads and power applications up to 15A at 250V AC, making it ideal for controlling heavy electrical devices and machinery.

The switch features a robust panel mount design with a 12.2 mm cutout size to ensure easy integration into control panels. The screw terminal connection method facilitates secure wiring installation. The actuator is constructed from durable brass, extends 17.5 mm, and provides reliable tactile feedback.

Constructed with terminal and contact supports made from a single piece of metal, the resistance-welded contacts enhance mechanical strength and ensure stable long-term operation. This toggle switch complies with UL, NF-VDE EN 61058-1, and CSA standards, delivering certified safety and reliability.

It is rated for an extended mechanical life of 10,000 cycles, suitable for frequent switching in demanding industrial environments. Operation is guaranteed within a temperature range of -20°C to 55°C, ensuring performance stability under varying environmental conditions. The switch is non-illuminated and intended for use in panel installations requiring manual control.

This model is manufactured in France and is part of APEM's 600H Series, well-regarded for quality and durability in tough industrial settings. SPDT contact configuration with On-Off-On switch operation. 15A, 250V AC rating for motor and power control applications.

Panel mount with 12.2 mm cutout and screw terminal connections. Durable brass actuator with 17.5 mm length. Certified with UL, NF-VDE EN 61058-1, and CSA standards. 10,000 mechanical cycles life expectancy. Operating temperature range: -20°C to 55°C.

Constructed from a single piece of metal for strength.

This toggle switch is suited for electrical, automation, and industrial control applications including manufacturing, machinery operation, and power distribution setups. Explore more Toggle Switch options from APEM at EnvMart for reliable industrial electrical components.
