TE Connectivity Panel Mount Toggle Switch SPDT On-On 24 V dc 240 V ac Solder Terminal 6-1825136-4

TE Connectivity 6-1825136-4 is a panel mount toggle switch with SPDT (Single Pole Double Throw) contact configuration and On-On switch operation. Rated for 24 V dc and 240 V ac, this switch is intended for robust switching applications in industrial and commercial systems.

The switch features a solder terminal type for secure electrical connections and an actuator made from phenolic material, offering mechanical strength and durability. Its compact dimensions (width 0.270 in, length 0.5 in) make it ideal for panel mounting in control panels and electrical assemblies.

Rated at 5 A contact current, this toggle switch can efficiently manage moderate electrical loads. It exhibits excellent ingress protection with an IP68S rating, suitable for use in harsh environments where moisture and dust resistance are required.

Operating temperature range from -30°C to 85°C enables this switch to function reliably across diverse working conditions, making it suitable for applications in industrial automation, electrical appliances, and control circuits in manufacturing and HVAC systems.

With mechanical life rated at 6000 cycles, the switch offers dependable performance over extended operation periods. The design complies with multiple international standards including RoHS, cULus, EN, IEC, and UL, ensuring safety and environmental compliance.

The switch supports a maximum contact current of 5 A ensuring reliable circuit control. Equipped with solder terminals for secure electrical connections. Designed with an IP68S rating providing excellent environmental protection.

Features a phenolic actuator material and a panel cutout size of 6.35 mm. Operates reliably between temperatures of -30°C to 85°C. Rated for 6000 mechanical cycles, ensuring durable performance. Compact dimensions with width 0.270 inches and length 0.5 inches facilitate easy panel mounting.

Built to meet standards including RoHS, cULus, EN, IEC, and UL.

This TE Connectivity toggle switch is ideal for use in electrical panels, industrial automation control systems, and applications requiring reliable switching with high ingress protection. It enables precise control in varied environments and is well suited for engineers and designers demanding robust, certified components.
