Gems Sensors 3200 Series Pressure Sensor Analogue Output 0 to 250 bar 9-30 V dc 1 ms Response 3200B0250S05ER00

Gems Sensors 3200B0250S05ER00 Pressure Sensor from the 3200 series provides high-precision pressure measurement with analogue output suitable for industrial and automation contexts. This sensor accurately measures relative pressure from 0 to 250 bar in fluids such as oil, hydraulic fluids, and air.

The device supports a supply voltage between 9 V and 30 V dc and delivers a quick response time of 1 ms. It is designed to operate reliably in extreme temperatures ranging from -40°C up to 125°C. The sensor's wetted parts are made entirely of stainless steel, enhancing durability and corrosion resistance in demanding applications.

The sensor features an IP67 and IP65 rating, protecting against dust ingress and water jets, making it ideal for harsh industrial environments. Its compact size allows installation in tight spaces using M12 electrical connections. RoHS compliance confirms environmentally responsible manufacturing.

Applications include hydraulic and pneumatic system monitoring, industrial automation equipment, water treatment plants, manufacturing process control, and other scenarios requiring precise fluid pressure sensing.

Operates with supply voltage range from 9 V to 30 V dc. Provides analogue output type with fast 1 ms response time. Features high accuracy of 0.25% full scale with broad operating temperature from -40°C to 125°C. IP67 and IP65 rated for robust environmental protection.

Constructed with stainless steel wetted parts for durability and corrosion resistance. M12 connections facilitate compact and secure installation in tight spaces. RoHS compliant ensuring adherence to environmental safety standards.

Manufactured in the United Kingdom for quality assurance. Discover the comprehensive range of industrial sensors available in EnvMart to find the perfect fit for your industrial measurement and control needs.
