Microchip Operational Amplifier 1.3 MHz Gain Bandwidth, 8-Pin SOIC, 3-5.5 V MCP6V02-E/SN

Free Delivery in India | Lowest Global Shipping Charges

Microchip Operational Amplifier 1.3 MHz Gain Bandwidth, 8-Pin SOIC, 3-5.5 V MCP6V02-E/SN

Name: Microchip Operational Amplifier 1.3 MHz Gain Bandwidth, 8-Pin SOIC, 3-5.5 V MCP6V02-E/SN
Brand: Microchip
SKU: 205009
Price: 4.05 USD
Availability: InStock



Category Operational Amplifier Brand Microchip Condition New

Specifications

Country of Origin	India
Brand	Microchip
Height	1.25mm
Length	4.9mm
Model	MCP6V02-E/SN
Width	3.9mm
Mount Type	Surface
Series	MCP6V02
Output Current	30mA
Maximum Operating Temperature	125°C
Package Type	SOIC
Minimum Operating Temperature	-40°C
Number Of Channels	2
Standards/Approvals	RoHS
Pin Count	8
Automotive Standard	AEC-Q100
Maximum Supply Voltage	5.5V
Minimum Supply Voltage	3V
GBP - Gain Bandwidth Product	1.3MHz
Input Bias Current	1 pA
Slew Rate	0.5V/μs
Input Offset Current	-30 pA

Key Features

Operates within a supply voltage range of 3 V to 5.5 V.
Offers low input bias current of 1 pA for high-precision applications.
Contains 2 channels and 8 pins for versatile usage.
Features a slew rate of 0.5 V/μs suitable for moderate speed amplification.
Wide operating temperature range from -40°C to 125°C supports harsh environments.
Compliant with RoHS standards and Automotive AEC-Q100 qualification.
Output current capacity up to 30 mA enables driving various loads.
Low input offset voltage of 2 μV ensures accuracy in signal processing.

Product Description

Microchip MCP6V02-E/SN is a dual-channel operational amplifier designed for precise amplification tasks in electronic circuits. It operates at a gain bandwidth product of 1.3 MHz, enabling efficient processing of moderate frequency signals. The 8-pin SOIC surface mount package ensures compatibility with compact PCB layouts.

This device supports a supply voltage from 3 V up to 5.5 V, making it adaptable for various power environments. Its low input bias current of 1 pA and minimal input offset voltage of 2 μV allow highly accurate signal amplification, suitable for sensitive measurement and control systems.

The operational amplifier is robust for use in automotive and industrial applications, meeting the stringent AEC-Q100 standard and sustaining performance across a temperature range of -40°C to 125°C. Its maximum output current of 30 mA facilitates the driving of modest loads effectively.

Physical dimensions are compact (4.9 mm length, 3.9 mm width, and 1.25 mm height), optimizing PCB real estate utilization. The MCP6V02 series complies with RoHS environmental standards, aligning with modern manufacturing and sustainability requirements.

Operates between 3 V and 5.5 V supply voltages. Dual channel design enhances flexibility for multi-signal tasks. Low input bias and offset currents minimize signal error. Suitable for automotive and industrial applications with AEC-Q100 compliance.

Compact SOIC package supports surface mounting on PCBs. Moderate slew rate of 0.5 V/μs for balanced speed and stability. Environmental compliant with RoHS regulations. Max output current of 30 mA ideal for driving external components.

This Operational Amplifier is an excellent choice for engineers focusing on reliable and accurate analog signal processing in electronic design. Explore our comprehensive Electronics & Electricals category for more Semiconductor Amplifiers and related components on EnvMart.
