MEAN WELL 2 W Surface Mount Switching Power Supply 15V DC, Universal Input 85-305V AC IRM-02-15S

MEAN WELL IRM-02-15S is a 2 W single output encapsulated Switching Power Supply designed for surface mounting on PCBs. It provides a stable 15V DC output voltage with a maximum current of 133mA, making it suitable for compact and low power industrial electronics and handheld devices.

The power supply accepts a broad universal input voltage range from 85V AC up to 305V AC, or up to 430V DC, allowing versatile use worldwide. Its compact dimensions (33.7mm length x 22.2mm width x 16mm depth) and lightweight 19g construction aid in PCB integration without adding bulk.

The unit is constructed with a phenolic case and fully potted with silicone to ensure resistance against vibration up to 5G, dust, and moisture ingress. This encapsulated design also assists with effective heat dissipation via free air convection cooling.

High efficiency of up to 77% reduces power loss and heat generation. Features integrated include overvoltage, overload, and short circuit protection to ensure device and operator safety in demanding environments.

The IRM-02 series complies with international safety and EMC standards including UL 60950-1, TUV EN 60950-1, IEC 62368-1, and EN 55022 Class B EMC emission limits, facilitating worldwide regulatory acceptance.

Typical applications include factory automation equipment, industrial electrical instruments, mechanical equipment, and handheld electronic devices requiring a reliable low power supply.

This power supply is a Class II insulation device with built-in EMI filtering components to minimize electromagnetic interference, making it ideal for industrial and commercial electronics.

Choose MEAN WELL IRM-02-15S for versatile, reliable, and compact 15V DC power supply needs in industrial, laboratory, and manufacturing environments. Explore more power supply options and industrial electronics components on EnvMart.

Universal AC input voltage range from 85V to 305V AC provides versatile operation. Maximum output current is 133mA with high efficiency up to 75%. Operating temperature range extends from -30°C to 85°C for reliable performance.

Features full encapsulation with phenolic case and silicone potting for durability and anti-vibration resistance. Includes protection against overvoltage, overload, and short circuit conditions. Compliance with multiple safety standards including UL 60950-1 and TUV EN 60950-1.

Suitable for industrial, factory automation, and handheld electronic applications. Compact dimensions of 33.7mm length, 22.2mm width, and 16mm depth facilitate PCB mounting. Designed for low electromagnetic interference with built-in EMI filtering and EMC compliance.
