KYOCERA AVX 1.5 nF 2kV DC Multilayer Ceramic Capacitor, ±10 % Tolerance, Surface Mount 1808 Package 1808GC152KAT1A

KYOCERA AVX 1808GC152KAT1A Multilayer Ceramic Capacitor is a high-performance passive component designed for industrial electronics. Featuring a 1.5 nF capacitance with ±10 % tolerance, it is rated for 2kV DC maximum voltage to ensure stable operation in demanding high-voltage environments. Using X7R dielectric material, this capacitor maintains consistent capacitance within ±0.3% over a broad operating temperature range from -55°C up to 125°C. The surface mount 1808 package with compact dimensions of 4.6mm length, 2mm width, and 2.2mm height enables use in space-constrained printed circuit boards.

This component is ideal for applications including snubbers in high frequency power electronics, resonators in switched-mode power supplies (SMPS), high-voltage coupling, and DC blocking. The FLEXITERM series termination provides reliable solder joints for surface mount technology (SMT) assembly. Its low equivalent series resistance (ESR) at high frequencies ensures efficient performance and minimal signal distortion.

Packaged on reels, the capacitor is suited for automated pick-and-place manufacturing, supporting large scale production runs. The product is new, RoHS compliant, and built without automotive standards classification.

This capacitor uses X7R dielectric, offering stability over a -55°C to 125°C temperature range. It supports high-voltage applications with a maximum operating voltage of 2kV DC. The surface mount termination enables reliable soldering in automated PCB assembly.

Compact dimensions of 4.6mm length, 2mm width, and 2.2mm height fit dense electronic designs. Capacitance variation remains minimal with temperature coefficient near 0 ±30ppm/°C. Suitable for snubbers, high frequency power converters, resonators in SMPS, and DC blocking uses.

Reel packaging supports efficient mass production assembly processes.

The KYOCERA AVX product line is well-recognized for precision and durability, widely used across industrial, telecommunications, automotive auxiliary electronics (not automotive grade in this case), and consumer electronic applications. Browse EnvMart for additional MLCCs and passive components suited to your design needs.
