TE Connectivity SL-156 Female Connector Housing 3.96 mm Pitch 7 Way 1 Row Straight 640250-7
Specifications
| Country of Origin | India |
|---|---|
| Brand | TE Connectivity |
| Orientation | Straight |
| Length | 27.69mm |
| Model | 640250-7 |
| Width | 16.76mm |
| Mount Type | Cable |
| Housing Material | Nylon |
| Series | SL-156 |
| Number of Rows | 1 |
| Pitch | 3.96mm |
| For Use With | Wire-to-Board Connector |
| Number of Contacts | 7 |
| Connector Gender | Female |
Key Features
- Designed for 7-way connections with a 3.96 mm pitch.
- Single row female connector housing ensuring compact installation.
- Constructed from high-quality nylon with UL94V-0 rating for enhanced flame resistance.
- Suitable for wire-to-board connectors in electronic and electrical applications.
- Features a straight cable mount type orientation for easy assembly.
- Compatible with 18 to 24 AWG wire sizes for broad application range.
- Stackable end to end with locking ramp and polarizing tabs options available.
Product Description
The TE Connectivity 640250-7 female connector housing is part of the SL-156 series, designed with a 3.96 mm pitch and 7 contacts arranged in a single row. It is a straight orientation connector housing suitable for wire-to-board connections in various electronics and electrical applications.
This connector housing is crafted from UL94V-0 rated nylon material ensuring robustness and flame resistance, making it ideal for demanding conditions. Its design allows stacking end-to-end for flexible configurations, incorporating features like locking ramp mating retention and polarizing tabs for secure and accurate connections.
The connector accommodates wire sizes from 18 to 24 AWG and is engineered for a cable mount type. The overall dimensions are 27.69 mm in length and 16.76 mm in width, providing a compact footprint suitable for PCB mounting.
These housings mate with 1.14 mm square or round post headers or staked posts on 0.156 inch centers, optimizing compatibility with a range of header styles. This product is widely used in industrial, commercial, and electronics manufacturing sectors for reliable wire housing solutions.
7-way female connector housing with 3.96 mm pitch. Single row straight cable mount design for ease of integration. Manufactured from flame-retardant nylon (UL94V-0 rating). End-to-end stackable for modular configurations.
Accommodates wire size range 18 to 24 AWG. Locking ramps and polarizing tabs available for secure mating. Compact dimensions 27.69 mm length and 16.76 mm width.
This TE Connectivity SL-156 series Connector Housing ensures secure and efficient wire-to-board connections and meets industry standards for electronic components. Explore a wide selection of connector solutions in the Electronics & Electricals categories at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch size of this connector housing is 3.96 mm.
This connector housing features 7 contacts arranged in a single row.
It accommodates wire sizes ranging from 18 to 24 AWG.
The housing is constructed from nylon with a UL94V-0 rating for enhanced flame resistance.
The overall dimensions are 27.69 mm in length and 16.76 mm in width.
It is designed for a cable mount type orientation.
Yes, it is stackable end-to-end for flexible configurations.
It includes locking ramps and polarizing tabs for secure mating.
The country of origin for this connector housing is India.
This model is part of the SL-156 series.
It is suitable for wire-to-board connections in various electronic and electrical applications.
This connector housing has a female connector gender.
