Phoenix Contact Circular Connector Cable Mount, 4 Contacts, M12 Socket Female, IDC Termination, IP65 IP67, 250V, 9A 1642140
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 250V |
| Brand | Phoenix Contact |
| Orientation | Straight |
| Current | 9A |
| Model | 1642140 |
| IP Rating | IP65, IP67 |
| Mount Type | Cable |
| Housing Material | Polyamide |
| Contact Material | Steel |
| Series | Q 0.75 |
| Termination Type | IDC |
| Maximum Operating Temperature | 80°C |
| Minimum Operating Temperature | -40°C |
| Contact Plating | Tin |
| Number of Contacts | 4 |
| Contact Gender | Female |
| Shell Size | 15 mm |
| Mating Type | Quick Connect |
| Connector Size | M12 |
| Plug/Socket | Socket |
| Phoenix Contact IDC ConnectorBrand | Phoenix Contact |
Key Features
- Designed for quick connect cable extensions with self-stripping QUICKON technology.
- Rated for operating voltage up to 250 V and current capacity of 9 A.
- Suitable for use in process and control applications requiring secure and water-tight connectivity.
- Features polyamide housing, tin-plated steel contacts, and straight orientation.
- Operates reliably between -40°C and 80°C temperature range.
- Provides IP67 ingress protection, allowing submersion up to 1 meter for 1 hour.
- Compact design with 15 mm shell size nut for secure panel mounting.
- Meets RoHS directive and electrostatic discharge standards for safety and durability.
Product Description
Phoenix Contact 1642140 circular connector cable mount features 4 contacts in an M12 socket female configuration with IDC insulation displacement contact termination technology. The connector is designed for industrial applications demanding high reliability and ease of use, such as process control and automation systems.
This cable mount connector supports an operating voltage of 250 V and handles currents up to 9 A. It incorporates QUICKON quick-connect self-stripping cable extensions to simplify installation and maintenance by eliminating the need for stripping wires manually. The cable gland system design ensures a secure and watertight connection, contributing to its IP65 and IP67 ingress protection ratings.
The polyamide housing and tin-plated steel contacts provide robust mechanical and electrical performance while maintaining resistance to corrosion and environmental stress. The connector's straight orientation and 15 mm nut shell size facilitate easy panel attachment and mounting.
Rated for operation in temperature extremes from -40°C up to 80°C, this connector is suitable for harsh industrial environments. It complies with the Restriction of Hazardous Substances (RoHS) directive, guaranteeing low hazardous material content, and meets ANSI/ESD S20.20:2014 and BS EN 61340-5-1:2007 electrostatic discharge control standards, protecting sensitive equipment from damage.
This M12 circular connector is ideal for extending or repairing round cables in industrial process applications requiring secure, reliable, and waterproof connections. Its compact design and durable construction make it a trusted choice for manufacturing, industrial automation, water treatment, and control systems.
Quick connect self-stripping QUICKON cable extensions enable fast assembly. Rated for 250 V voltage and 9 A current capacity suitable for extensive industrial use. Polyamide housing and tin-plated steel contacts provide durability and corrosion resistance.
IP65 and IP67 ratings protect against dust ingress and water submersion. Operating temperature range from -40°C to 80°C for wide environmental adaptability. Complies with RoHS and electrostatic discharge standards ensuring material safety and equipment protection.
Explore the Electronics & Electricals category for more industrial connectors and circular connector solutions with trusted Phoenix Contact quality at EnvMart.
Explore more products in our Industrial Circular Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This connector supports a maximum operating voltage of 250 V and a current capacity of 9 A.
It has an ingress protection rating of IP65 and IP67, allowing for protection against dust and water submersion up to 1 meter for 1 hour.
The housing is made of polyamide, and the contacts are tin-plated steel, providing durability and corrosion resistance.
It operates reliably in a temperature range from -40°C to 80°C.
This M12 socket features 4 contacts.
It utilizes IDC (Insulation Displacement Contact) termination technology for easy installation.
The shell size for this connector is 15 mm, which aids in secure panel mounting.
This model has a straight orientation, making it suitable for various installation scenarios.
It is designed for use in industrial applications such as process control and automation systems requiring reliable and waterproof connections.
Yes, it complies with the RoHS directive and meets electrostatic discharge control standards ANSI/ESD S20.20:2014 and BS EN 61340-5-1:2007.
This connector is designed for cable mounting, facilitating easy integration into existing setups.
It features a quick connect mating type, allowing for fast and efficient assembly.
