HARWIN M22 Series Straight Through Hole Pin Header, 10 Contacts, 2 mm Pitch, 1 Row, Unshrouded M22-2011005

Free Delivery in India | Lowest Global Shipping Charges

HARWIN M22 Series Straight Through Hole Pin Header, 10 Contacts, 2 mm Pitch, 1 Row, Unshrouded M22-2011005

Name: HARWIN M22 Series Straight Through Hole Pin Header, 10 Contacts, 2 mm Pitch, 1 Row, Unshrouded M22-2011005
Brand: HARWIN
SKU: 201079
Price: 0.59 USD
Availability: InStock



Category PCB Pin Header Brand HARWIN Condition New

Specifications

Country of Origin	India
Brand	HARWIN
Orientation	Straight
Current	1A
Model	M22-2011005
Mount Type	Through Hole
Housing Material	Nylon
Contact Material	Phosphor Bronze
Series	M22
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-40°C
Number of Rows	1
Pitch	2mm
Contact Plating	Gold
Number of Contacts	10
Contact Gender	Male
Shrouded/Unshrouded	Unshrouded
Connector System	Board-to-Board
Tail Pin Length	3.4mm
Mating Pin Length	3.5mm

Key Features

Constructed with durable nylon housing that withstands high temperature soldering.
Phosphor bronze male contacts plated with gold for excellent conductivity and corrosion resistance.
Pitch of 2 mm and 10 contacts arranged in a single row for flexible circuit connections.
Designed for board-to-board connector systems with through-hole mount type.
Operating temperature range from -40°C to 105°C ensuring reliability in various environments.
Solder termination type with 3.4 mm tail pin length and 3.5 mm mating pin length for secure connections.
Unshrouded design for easier inspection and soldering.
No applicable industry standards or approvals specified.

Product Description

HARWIN M22-2011005 is a high-quality straight through-hole pin header connector designed for circuit boards requiring a reliable and versatile board-to-board connection. This 10-contact connector features a 2 mm pitch with a single row of male pins, crafted from phosphor bronze with gold plating to ensure superior electrical conductivity and resistance to corrosion.

The connector housing is made from high temperature nylon thermoplastic, enabling it to endure reflow soldering processes and providing robustness in demanding environments. The unshrouded configuration simplifies inspection and soldering operations while allowing flexibility in system design.

Operating over a wide temperature range from -40°C to 105°C, this pin header is well suited for consumer electronics, communication devices, industrial monitoring, embedded PC systems, and motherboard applications. It supports solder tail termination with a 3.4 mm pin length for a secure and stable connection.

The M22 series headers can be cut to size as needed due to castellated housing design, enhancing customizability. These connectors pair seamlessly with M22 series PC sockets, housings, and jumpers, making them a standard solution in various electronic assembly processes.

Durable nylon housing withstands high temperature soldering. Phosphor bronze male contacts with gold plating enhance performance. 2 mm pitch with 10 contacts in a straight, single-row layout. Designed for through-hole mounting board-to-board connections.

Operating temperature range from -40°C to 105°C. 3.4 mm tail and 3.5 mm mating pin lengths ensure secure connectivity. Unshrouded design for easy access and inspection. Compatible with M22 sockets and jumpers for system flexibility.

This HARWIN M22 series pin header is ideal for industrial, consumer electronics, telecommunications, and embedded systems applications. Explore our extensive range of connectors and electronic components on EnvMart for advanced circuit board solutions.

Explore more products in our PCB Pin Header category.
