HARWIN M22 Series Straight Through Hole 36 Contact Pin Header 2 mm Pitch 2 Row Unshrouded M22-2021846
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 650V |
| Brand | HARWIN |
| Orientation | Straight |
| Current | 1A |
| Model | M22-2021846 |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Phosphor Bronze |
| Series | M22 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 2mm |
| Contact Plating | Tin |
| Number of Contacts | 36 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 3.4mm |
| Mating Pin Length | 3.5mm |
| Harwin, M22-202 2mm Pitch 36 Way,Through Hole Mount IC Dip Header, Tin, 1ABrand | Harwin |
Key Features
- Features unshrouded male contacts made of phosphor bronze with tin plating for reliable conductivity.
- Constructed with high-temperature nylon housing capable of withstanding reflow soldering processes.
- Mating pin length of 3.5 mm and tail pin length of 3.4 mm enable solid mechanical and electrical connections.
- Rated for 1A current and 650V voltage, operating between -40°C to 105°C for versatile applications.
- Suitable for board-to-board connection systems in embedded PCs, motherboards, and electronics systems.
- Can be trimmed to smaller sizes using castellations in housing to fit custom designs.
- Offers multiple configuration options for design flexibility in industrial and consumer electronics.
Product Description
The HARWIN M22-2021846 is a high-quality M22 Series 2.00 mm pitch PCB straight through hole pin header featuring 36 contacts arranged in two rows. Manufactured with a housing made from high-temperature thermoplastic nylon, this header supports reflow soldering processes crucial in modern PCB assembly.
This connector uses phosphor bronze male pins plated with tin to ensure excellent conductivity and mechanical robustness. The unshrouded design allows ease of access and compatibility with mating components in board-to-board systems.
The pins feature a mating length of 3.5 mm and a tail length of 3.4 mm, facilitating reliable electrical and mechanical connection through soldering onto PCBs. It supports a current rating of 1 ampere and a voltage rating of 650 volts, with an operating temperature range from -40°C up to 105°C, making it suitable for diverse environments.
Designed with castellations in the housing, the header can be cut down to smaller sizes if required, offering adaptability in electronics design. This versatility is advantageous in applications spanning consumer electronics, communications, drives, industrial monitoring, and embedded computing systems.
The M22 Series headers are widely accepted standards in motherboard and large electronic system assembly due to their robustness, easy integration, and flexibility in configurations including vertical and right-angle styles.
Features unshrouded male phosphor bronze pins plated with tin for durability. High temperature nylon housing withstands reflow soldering processes. 36 contacts configured in 2 rows for compact design. 2.00 mm pitch suits standard PCB applications.
Supports 1A current and 650V voltage ratings. Operating temperature range from -40°C to 105°C ensures reliability. Castellated housing allows size customization for various PCB layouts.
This HARWIN M22-2021846 pin header is ideal for use in electronics manufacturing, laboratory prototyping, industrial automation, communication devices, and more where dependable board-to-board connections are required.
Explore more connectors and PCB headers at EnvMart to complete your electronic assembly needs.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this pin header is 2.00 mm, suitable for standard PCB applications.
It is rated for a current of 1 ampere and a voltage of 650 volts.
The contacts are made of phosphor bronze with tin plating, while the housing is constructed from high-temperature nylon.
The operating temperature range is from -40°C to 105°C, making it suitable for diverse environments.
This pin header features 36 contacts arranged in two rows.
It uses a solder termination type for connecting to PCBs.
Yes, the castellated housing allows it to be trimmed to smaller sizes to fit custom designs.
The orientation of this pin header is straight, designed for through-hole mounting.
It supports a board-to-board connector system, ideal for embedded PCs and motherboards.
The mating pin length is 3.5 mm, and the tail pin length is 3.4 mm.
The country of origin for this pin header is Taiwan.
It is suitable for applications in consumer electronics, communications, industrial monitoring, and embedded computing systems.
