Cosel Switching Power Supply 24V DC 504W PCB Mount GHA500F-24-R3

Free Delivery in India | Lowest Global Shipping Charges

Cosel Switching Power Supply 24V DC 504W PCB Mount GHA500F-24-R3

Name: Cosel Switching Power Supply 24V DC 504W PCB Mount GHA500F-24-R3
Brand: Cosel
SKU: 200956



Category Switching Power Supplies Brand Cosel Condition New

Specifications

Country of Origin	Japan
Brand	Cosel
Power	504W
Efficiency	92%
Length	127mm
Model	GHA500F-24-R3
Depth	35mm
Gross Weight	420g
Width	76.2mm
Mount Type	PCB
Series	GHA500F
Maximum Operating Temperature	80°C
Minimum Operating Temperature	-20°C
Number of outputs	1
Maximum Input Voltage	264V ac
Standards/Approvals	UL, RoHS, cURus, CE
Maximum Output Voltage	24V dc
SMPS Output Current	4.6A
Minimum Input Voltage	90V ac

Key Features

Universal input voltage range from 90V AC to 264V AC.
Output current rated at 4.6A ensuring consistent power delivery.
High efficiency of 92% reduces energy losses during operation.
Wide operating temperature range from -20°C to 80°C for reliable performance.
Compact dimensions measuring 127mm in length, 76.2mm in width, and 35mm in depth.
Mounts directly on PCB for space-saving installation.
Includes built-in protections for overcurrent, overvoltage, and inrush current.
Compliant with safety standards UL, RoHS, cURus, and CE.

Product Description

Cosel GHA500F-24-R3 is a high-performance switching power supply designed for industrial and medical applications. This compact unit outputs a stable 24V DC at 504W power, suitable for embedded systems requiring reliable DC power. The power supply features a single output and is designed for PCB mounting, facilitating easy integration into electronic assemblies.

It operates over a broad input voltage range of 90V to 264V AC and delivers a maximum output current of 4.6A. Its high efficiency of 92% ensures lower heat generation and energy savings during continuous operation. The device maintains stable performance across harsh environments with an operating temperature range from -20°C to 80°C.

Safety and reliability are emphasized through compliance with multiple certifications, including UL, RoHS, cURus, and CE approvals. The power supply also incorporates internal dual fuses, harmonic attenuation meeting IEC61000-3-2 Class A, and power factor correction circuitry, improving overall electrical performance.

Additional protection features include inrush current limiting, overcurrent, and overvoltage protection circuits, enhancing durability and safeguarding attached equipment. Optional features such as remote ON/OFF control and auxiliary outputs (12V and 5V) provide flexibility for complex system integrations.

The compact form factor measuring 127mm length, 76.2mm width, and 35mm depth fits well within 1U rack applications. With a gross weight of 420 grams, it is lightweight for embedded system use. Manufactured in Japan, this switching power supply reflects premium quality guaranteed by a five-year warranty.

Universal input voltage range from 90V AC to 264V AC. Output current rated at 4.6A ensuring consistent power delivery. High efficiency of 92% reduces energy losses during operation. Wide operating temperature range from -20°C to 80°C for reliable performance.

Compact dimensions measuring 127mm in length, 76.2mm in width, and 35mm in depth. Mounts directly on PCB for space-saving installation. Includes built-in protections for overcurrent, overvoltage, and inrush current. Compliant with safety standards UL, RoHS, cURus, and CE.

Ideal for industrial and medical applications requiring stable DC power. Manufactured in Japan ensuring high-quality craftsmanship. Explore more Switching Power Supplies and advanced electronic components at EnvMart for your industrial and technical system requirements.
