Vishay Single Layer Ceramic Capacitor 3.3 nF 40kV dc Y5U Dielectric Screw Terminal 85 °C Max Op. Temp 715C40DKD33

Free Delivery in India | Lowest Global Shipping Charges

Vishay Single Layer Ceramic Capacitor 3.3 nF 40kV dc Y5U Dielectric Screw Terminal 85 °C Max Op. Temp 715C40DKD33

Name: Vishay Single Layer Ceramic Capacitor 3.3 nF 40kV dc Y5U Dielectric Screw Terminal 85 °C Max Op. Temp 715C40DKD33
Brand: Vishay
SKU: 200914
Price: 20.22 USD
Availability: InStock



Category Single Layer Ceramic Capacitors Brand Vishay Condition New

Specifications

Country of Origin	Germany
Voltage	40kV dc
Diameter	58.4mm
Brand	Vishay
Height	34.5mm
Model	715C40DKD33
Mount Type	Screw
Series	715C
Maximum Operating Temperature	85°C
Tolerance	-20 to 80 %
Capacitance	3.3nF
Minimum Operating Temperature	-30°C
Terminal type	Screw
Dissipation Factor	0.02%
Standards/Approvals	EC, RoHS, IEC 61249-2-21
Package/Case	0814
Dielectric	Y5U
Suppression Class	Class II

Key Features

High voltage ceramic disc capacitor designed for industrial applications.
Screw terminal mounting offers secure connection and low inductance.
Epoxy coated insulation ensures high insulation resistance.
Operating temperature range from -30°C to 85°C.
Capacitance tolerance of -20 to 80% for stable performance.
Complies with EC, RoHS, IEC 61249-2-21 standards for quality assurance.
Package case size 0814 with a diameter of 58.4mm and height of 34.5mm.
Low dissipation factor of 0.02% for efficient operation.

Product Description

Vishay 715C40DKD33 is a single layer ceramic capacitor featuring a capacitance of 3.3 nF and a high DC voltage rating of 40kV. It uses a Y5U dielectric material with a screw terminal mounting type, making it suitable for applications requiring low inductance and high insulation resistance.

This capacitor is epoxy coated for enhanced durability and electrical insulation, with an operating temperature range of -30°C to 85°C, ensuring performance stability in demanding industrial environments. Its capacitance tolerance ranges from -20% to 80%, suitable for varying electrical requirements.

The physical dimensions include a diameter of 58.4 mm and a height of 34.5 mm, housed in an 0814 case. The low dissipation factor of 0.02% helps maintain energy efficiency during use.

It meets the EC, RoHS, and IEC 61249-2-21 standards and features a Class II suppression rating, certifying its quality and safety compliance. This capacitor is ideal for industrial sectors including high voltage power supplies, X-ray machines, welding equipment, and other high voltage applications requiring reliable component performance.

High voltage ceramic disc capacitor with screw terminal mounting. Epoxy coated insulation provides high insulation resistance. Low inductance design for improved electrical characteristics. Operating temperature range from -30°C to 85°C.

Capacitance tolerance of -20 to 80% ensures operational flexibility. Complies with EC, RoHS, IEC 61249-2-21 standards. Package size 0814 with diameter 58.4 mm and height 34.5 mm. Low dissipation factor of 0.02%. Suitable for industrial, high voltage power, X-ray, and welding equipment.

Manufactured in Germany for high quality and reliability. Explore more high-quality capacitors and electronic components in the Electronics & Electricals category on EnvMart for your industrial and commercial needs.
