Vishay Single Layer Ceramic Capacitor 500pF 20kV dc Y5U Dielectric Screw Terminal 715C20DKT50
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 20kV dc |
| Diameter | 22.4mm |
| Brand | Vishay |
| Height | 25.4mm |
| Model | 715C20DKT50 |
| Mount Type | Screw |
| Series | 715C |
| Maximum Operating Temperature | 85°C |
| Tolerance | -20 to 80 % |
| Capacitance | 500pF |
| Minimum Operating Temperature | -30°C |
| Terminal type | Screw |
| Dissipation Factor | 0.02% |
| Standards/Approvals | EC, IEC 61249-2-21, RoHS |
| Package/Case | 0814 |
| Dielectric | Y5U |
| Suppression Class | Class II |
Key Features
- Features screw terminal mount type for secure connection.
- Operating temperature range from -30°C to 85°C.
- Tolerance range of -20% to 80% for capacitance.
- Package case size 0814 with 25.4mm height and 22.4mm diameter.
- High insulation resistance with low inductance epoxy coated design.
- Compliant with EC, IEC 61249-2-21, and RoHS standards.
- Suppression class II suitable for high voltage applications.
Product Description
Vishay 715C20DKT50 single layer ceramic capacitor offers a capacitance of 500pF with high voltage rating up to 20kV dc. Designed with Y5U dielectric and screw terminal mounting, it ensures reliable performance under demanding conditions. The capacitor operates effectively within a temperature range of -30°C to 85°C, making it suitable for industrial and high voltage power supply applications.
The 715C series features an epoxy coated insulation that provides low inductance and high insulation resistance. This model is especially suited for use in x-ray equipment, welding systems, and other industrial equipment requiring stable, high-voltage capacitive components.
With a package case size of 0814, height of 25.4mm, and diameter of 22.4mm, the capacitor combines compact dimensions with robust build quality. It complies with international standards including EC, IEC 61249-2-21, and RoHS, ensuring environmental compliance and reliability.
Secure screw terminal mounting. Wide capacitance tolerance of -20 to 80 %. Class II suppression for noise reduction. Epoxy coated for durability and insulation. High insulation resistance for stable operation. Suitable for industrial, laboratory, and electrical power supply applications.
RoHS compliant to ensure environmental safety.
This capacitor is an industrial-grade component ideal for electronics manufacturing, high voltage circuitry, water treatment controls, and scientific instrumentation. Its proven durability and electrical properties make it a reliable choice for demanding applications.
Explore Vishay capacitors and related electronic components at EnvMart for high-quality parts designed for precision and reliability in electrical systems.
Explore more products in our Single Layer Ceramic Capacitors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Vishay 715C20DKT50 capacitor has a capacitance of 500pF.
This model is rated for a maximum voltage of 20kV dc.
The operating temperature range is from -30°C to 85°C.
It features a screw terminal mount type for secure connection.
The capacitor has a height of 25.4mm and a diameter of 22.4mm, with a package case size of 0814.
The tolerance range for this capacitor is -20% to 80%.
This model uses Y5U dielectric material.
It complies with EC, IEC 61249-2-21, and RoHS standards.
The suppression class is Class II, suitable for noise reduction in high voltage applications.
The dissipation factor for the Vishay 715C20DKT50 is 0.02%.
It is suitable for high voltage applications such as x-ray equipment and welding systems.
This capacitor is manufactured in Germany.
