ABB xEffect Miniature Circuit Breaker, 3-Pole, 6A, Type C, 400V AC, 10 kA Breaking Capacity 278867 FAZ-C6/3

Free Delivery in India | Lowest Global Shipping Charges

ABB xEffect Miniature Circuit Breaker, 3-Pole, 6A, Type C, 400V AC, 10 kA Breaking Capacity 278867 FAZ-C6/3



Category Miniature Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Romania
Range	xEffect
Brand	ABB
Model	278867 FAZ-C6/3
Depth	74mm
IP Rating	IP20
Width	52.5mm
Mount Type	DIN Rail
Current Rating	6A
Series	xEffect
Terminal type	Twin-Purpose Terminal
Breaking Capacity	10kA
Number of Poles	3
Rated AC Voltage	400V ac
Tripping Characteristics	Type C
Tripping Mechanism	Thermal Magnetic
Reset Actuator Type	Toggle Switch
Break Time	Instantaneous
MCB Module widths	1P 17.5mm, 2P 35mm and 3P 52.5mm

Key Features

Designed to protect electrical networks from overload and short circuits.
Type C tripping for instantaneous response at 5 to 10 times rated current.
Suitable for 400V AC applications with 10 kA breaking capacity.
Mounts easily on DIN rails with compact 52.5 mm width for 3 poles.
Features thermal magnetic tripping mechanism and toggle switch actuator.
Status indication via toggle switch position and color-coded indicator.
Terminal has twin-purpose design for wiring flexibility.
IP20 rated for finger protection and safety.

Product Description

Eaton 278867 FAZ-C6/3 miniature circuit breaker is a 3-pole device engineered for industrial and commercial electrical protection. It supports a current rating of 6A and provides type C tripping characteristics, making it ideal for circuits requiring rapid disconnection in the event of overloads or short circuits.

This MCB operates on 400V AC networks and can interrupt fault currents up to 10 kA, ensuring robust protection for sensitive equipment and wiring. Its thermal magnetic tripping mechanism combines overload and short circuit sensing for enhanced safety and reliability.

The compact design features a 52.5 mm wide module suitable for DIN rail mounting in electrical distribution panels with limited space. The toggle switch actuator offers clear, color-indicated status for easy operation and troubleshooting. Furthermore, the twin-purpose terminals allow flexible wiring options, facilitating installation in various electrical configurations.

With an IP20 protection rating, the breaker resists accidental contact with live parts, increasing user safety. Its construction guarantees a mechanical lifespan rated for 10,000 operations, ensuring long-term durability for demanding industrial environments.

The Eaton FAZ series, including model 278867 FAZ-C6/3, is designed to safeguard control circuits, heavy machinery, and network segments against damaging electrical surges and faults. It is particularly suited for applications involving powerful induction motors, pumps, and other heavy electrical loads.

Protects against overloads and short circuits in industrial electrical systems. Instantaneous trip between 5 to 10 times rated current for fast fault clearance. High breaking capacity of 10 kA suitable for demanding electrical networks.

Flexible line or load-side power feed options for installation adaptability. Robust thermal magnetic trip mechanism improves operational safety. Compact DIN rail mount design for space-saving electrical panels. Clear visual indication of operational status via toggle switch.

Compliance with international standards and manufacturing reliability from Romania.
