TDK-Lambda DC/DC Converter 5V DC 300mA 9V DC Input Surface Mount 1.5W 85°C Max CC1R5-0505SR-E

Free Delivery in India | Lowest Global Shipping Charges

TDK-Lambda DC/DC Converter 5V DC 300mA 9V DC Input Surface Mount 1.5W 85°C Max CC1R5-0505SR-E

Name: TDK-Lambda DC/DC Converter 5V DC 300mA 9V DC Input Surface Mount 1.5W 85°C Max CC1R5-0505SR-E
Brand: TDK-Lambda
SKU: 199329
Price: 18.18 USD
Availability: InStock



Category DC/DC Converter Brand TDK-Lambda Condition New

Specifications

Country of Origin	Japan
Voltage	Converters / DC-DC Converters TDK-Lambda CC-E DC/DC Converter, 5V dc/ 300 mA, 9V
Brand	TDK-Lambda
Efficiency	77%
Length	16.51mm
Model	CC1R5-0505SR-E
Depth	8.8mm
Width	16.6mm
Mount Type	Surface
Series	CC-E
Maximum Operating Temperature	85°C
Package Type	Surface Mount
Minimum Operating Temperature	-40°C
Number of outputs	1
Maximum Output Power	1.5W
Maximum Input Voltage	9V dc
Minimum Input Voltage	4.5V
Number of Pins	7
Output Voltage 1	5V dc
Output Current 1	300mA
Output Voltage Adjustment Range	4.75 → 6 V
Isolation Voltage	500V ac

Key Features

The converter supports a wide input voltage range of 4.5V to 9V DC.
It offers a single output with an adjustable voltage range from 4.75V to 6V.
High efficiency of 77% ensures low power loss in operations.
The product features 7 pins and surface mounting package type for easy PCB integration.
It provides 500V AC isolation voltage, suitable for industrial and test applications.
Compact dimensions of 16.51mm length, 16.6mm width and 8.8mm depth optimize space usage.
The metal casing reduces radiated EMI and improves durability under harsh conditions.
Typical uses include test, measurement, broadcast, process control, and general industrial equipment.

Product Description

TDK-Lambda CC1R5-0505SR-E is a DC/DC Converter designed for reliable voltage conversion, providing 5V output voltage at a maximum output current of 300mA. This surface mount device operates within input voltage from 4.5V to 9V DC, delivering a maximum output power of 1.5W with an efficiency of 77%. It can withstand operating temperatures ranging from -40°C minimum to 85°C maximum, making it suitable for demanding industrial and electronic applications.

This converter uses a compact metal case for improved heat dissipation and reduced electromagnetic interference. It features 7 pins and is designed for easy PCB surface mounting, which reduces required PCB area and simplifies system configurations. The isolation voltage of 500V AC offers electrical separation between input and output circuits, enhancing safety and performance.

The CC1R5-0505SR-E series is often utilized in fields such as test and measurement equipment, broadcast systems, industrial process control, and general industrial electronics where stable, isolated power conversion is critical. Its open frame design without potting supports thermal management while maintaining a lightweight profile.

The converter supports a wide DC input voltage range from 4.5V to 9V. Output voltage can be adjusted between 4.75V and 6V to meet specific application needs. 7-pin surface mount package is optimized for space-limited PCB layouts.

High efficiency of 77% helps reduce power loss and heat generation. Robust operating temperature range from -40°C up to 85°C enables usage in harsh environments. 500V AC isolation enhances electrical safety and noise immunity.

Compact dimensions of 16.51mm x 16.6mm x 8.8mm suit compact electronic devices. Metal case construction improves durability and electromagnetic compatibility.

Originating from Japan, this new product is a trusted choice for reliable power conversion in industrial, laboratory, and electronic manufacturing settings. For comprehensive power and voltage conversion requires, explore the DC/DC Converter category on EnvMart and discover trusted brands and models to suit your application's demands.
