Schneider Electric LC2K Reversing Contactor, 230V ac Coil, 3-Pole, 9 A, 4 kW, 3 NO Contacts, 690V ac LC2K0910P7

Free Delivery in India | Lowest Global Shipping Charges

Schneider Electric LC2K Reversing Contactor, 230V ac Coil, 3-Pole, 9 A, 4 kW, 3 NO Contacts, 690V ac LC2K0910P7

Name: Schneider Electric LC2K Reversing Contactor, 230V ac Coil, 3-Pole, 9 A, 4 kW, 3 NO Contacts, 690V ac LC2K0910P7
Brand: Schneider Electric
SKU: 198151
Price: 166.5 USD
Availability: InStock



Category Reversing Contactor Brand Schneider Electric Condition New

Specifications

Country of Origin	France
Brand	Schneider Electric
Function	Motor Control, Resistive Load, Reversing
Length	58mm
Model	LC2K0910P7
Depth	57mm
Width	90mm
Mount Type	DIN Rail
Series	LC2K
Power Rating	4kW
Maximum Operating Temperature	50°C
Minimum Operating Temperature	-25°C
Terminal type	Screw
Number of Poles	3
Standards/Approvals	CCC, CSA, EAC, IEC, RoHS, UL
Contact Voltage	690V ac
Coil Voltage	230V ac
Normal State Configuration	3 NO
Better World Claim	Designed for Disassembly
Contact Current	9A
Number of Auxiliary Contacts	1
Auxiliary Contact Configuration	1 NO
Operational Current Ie	9A
Control Circuit Voltage Uc	230V ac
Contactor Application	Motor Control, Resistive Load
Pole and Throw Configuration	3
Ue Rated Voltage Power circuit	690 V AC 50/60 Hz, Signalling circuit
WEG CWCI0 Reversing Contactor, 230V ac Coil, 3-Pole, 9 A, 4 kW, 3 NO, 690VBrand	WEG

Key Features

Equipped with a 230V AC coil for reliable operation.
Designed with 3 poles and 3 normally open contacts for robust motor control.
Supports contact current rating of 9 A and power rating of 4 kW.
Compatible with DIN rail mounting for easy installation.
Incorporates 1 auxiliary contact with 1 normally open configuration.
Constructed to operate between -25°C and 50°C ambient temperatures.
Terminal connections use screw type for secure wiring.
Compliant with CCC, CSA, EAC, IEC, RoHS, and UL standards.

Product Description

Schneider Electric LC2K0910P7 is a high-performance reversing contactor featuring a 230V AC coil, designed specifically for motor control and resistive load applications. This contactor has a robust 3-pole design delivering a contact current of 9 A and a power rating of 4 kW at 690V AC, providing reliable switching performance for reversing motors and other control tasks.

The device includes three normally open contacts arranged for motor reversing functions along with one auxiliary normally open contact to support control circuitry. It is mounted on a DIN rail, ensuring quick and easy installation in electrical panels. The contactor is built with screw terminal connections for stable and secure wiring.

It operates effectively within ambient temperatures ranging from -25°C to 50°C, making it suitable for various industrial environments. The LC2K0910P7 meets international standards including CCC, CSA, EAC, IEC, RoHS, and UL, ensuring compliance with global safety and quality requirements.

This product is manufactured in France and incorporates sustainable design principles, including being designed for disassembly to facilitate recycling and maintenance. 230V AC coil voltage for efficient motor reversing.

3-pole contactor with 9 A contact current and 4 kW power rating at 690V AC. One auxiliary contact (1 NO) included for enhanced control functionality. Supports motor control, resistive load, and reversing applications. Mount type: DIN Rail for convenient installation.

Screw terminal type for secure electrical connections. Operating temperature range: -25°C to 50°C to suit diverse environments. Complies with CCC, CSA, EAC, IEC, RoHS, and UL standards. Manufactured in France with sustainable and disassemblable design.

This Schneider Electric Reversing Contactor is ideal for industrial automation, motor control, manufacturing processes, electrical maintenance, and HVAC control systems. Explore more in our Automation & Control Gear category to find compatible components and accessories.
