Schneider Electric LP2K Series Reversing Contactor, 24V DC Coil, 3-Pole, 9A, 4kW Power, 3 NO Auxiliary Contacts LP2K0901BD
Specifications
| Country of Origin | France |
|---|---|
| Brand | Schneider Electric |
| Function | Motor Control, Resistive Load, Reversing |
| Length | 58mm |
| Model | LP2K0901BD |
| Depth | 57mm |
| Width | 90mm |
| Mount Type | DIN Rail |
| Series | LP2K |
| Power Rating | 4kW |
| Maximum Operating Temperature | 50°C |
| Minimum Operating Temperature | -25°C |
| Terminal type | Screw |
| Number of Poles | 3 |
| Standards/Approvals | CCC, CSA, EAC, IEC, RoHS, UL |
| Contact Voltage | 690V ac |
| Coil Voltage | 24V dc |
| Normal State Configuration | 3 NO |
| Better World Claim | Designed for Disassembly |
| Contact Current | 9A |
| Number of Auxiliary Contacts | 2 |
| Auxiliary Contact Configuration | 2 NC |
| Operational Current Ie | 9A |
| Control Circuit Voltage Uc | 24V dc |
| Contactor Application | Motor Control, Resistive Load |
| Pole and Throw Configuration | 3 |
Key Features
- The contactor supports a 9A operational current and a power rating of 4 kW.
- It is designed with 3 normally open (NO) main contacts and 2 normally closed (NC) auxiliary contacts.
- Compact dimensions of 58mm length, 90mm width, and 57mm depth allow easy DIN rail mounting.
- The device operates efficiently within a temperature range from -25°C to 50°C, suitable for diverse environments.
- Screw clamp terminals provide secure electrical connections for reliable performance.
- Certified compliant with standards including CCC, CSA, EAC, IEC, RoHS, and UL to ensure safety and quality.
- Ideal for reversing motor control applications and resistive load management in industrial automation systems.
- Designed for disassembly to support sustainability and environmentally responsible maintenance.
Product Description
Schneider Electric LP2K0901BD Reversing Contactor is part of the LP2K series within the TeSys K range, designed specifically for reliable motor control in various industrial, automation, and electrical applications. With a 24V DC coil voltage, this reversing contactor enables safer control of motors and resistive loads with a contact current capacity of 9A and maximum contact voltage of 690V AC.
This compact device measures 58mm in length, 90mm in width, and 57mm in depth, facilitating straightforward DIN rail mounting in control panels. Its robust screw clamp terminals ensure a secure electrical connection while enabling easy wiring and maintenance.
Operating from -25°C up to 50°C, it is suitable for use in harsh industrial environments and outdoor installations. The contactor features 3 normally open main contacts and 2 normally closed auxiliary contacts for enhanced control signaling and automation flexibility.
The Reversing Contactor complies with international standards such as CCC, CSA, EAC, IEC, RoHS, and UL, reflecting adherence to rigorous safety and environmental directives. Additionally, its design supports disassembly for serviceability and environmental considerations.
Typical use cases include motor reversing in machinery, automation systems requiring reliable load control, and integration in industrial electrical installations demanding efficient and safe motor management.
The 3-pole design provides versatile motor control options. The 24 V DC coil ensures compatibility with standard control circuits. Screw clamp terminals enhance connection reliability. Wide temperature operation range extends usage versatility.
Auxiliary contacts support signaling and control functions. Certified to multiple international standards for quality assurance. Compact DIN rail mount design simplifies installation. Designed for disassembly to promote sustainable practices.
Explore the comprehensive range of Schneider Electric automation products at EnvMart for industrial and manufacturing applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The LP2K0901BD reversing contactor has a power rating of 4 kW.
This model supports an operational current of 9A.
The dimensions of this unit are 58mm in length, 90mm in width, and 57mm in depth.
The coil voltage for the LP2K0901BD is 24V DC.
It features 2 normally closed (NC) auxiliary contacts.
The maximum contact voltage for this model is 690V AC.
This unit operates efficiently within a temperature range from -25°C to 50°C.
It supports DIN rail mounting, making installation straightforward.
This reversing contactor complies with standards including CCC, CSA, EAC, IEC, RoHS, and UL.
It is designed for motor control and resistive load management, particularly in reversing applications.
This model uses screw clamp terminals for secure electrical connections.
Yes, it is suitable for use in harsh industrial environments and outdoor installations due to its operating temperature range.
