Schneider Electric TeSys K Reversing Contactor 48V AC Coil 3-Pole 6A 4kW 3 NO 690V AC LC2K0601E7
Specifications
| Country of Origin | France |
|---|---|
| Brand | Schneider Electric |
| Function | Motor Control, Resistive Load, Reversing |
| Length | 58mm |
| Model | LC2K0601E7 |
| Depth | 57mm |
| Width | 90mm |
| Mount Type | DIN Rail |
| Series | LC2K |
| Power Rating | 4kW |
| Maximum Operating Temperature | 50°C |
| Minimum Operating Temperature | -25°C |
| Terminal type | Screw |
| Number of Poles | 3 |
| Standards/Approvals | CCC, CSA, EAC, IEC, RoHS, UL |
| Contact Voltage | 690V ac |
| Coil Voltage | 48V ac |
| Normal State Configuration | 3 NO |
| Better World Claim | Designed for Disassembly |
| Contact Current | 6A |
| Number of Auxiliary Contacts | 1 |
| Auxiliary Contact Configuration | 1 NC |
| Operational Current Ie | 6A |
| Control Circuit Voltage Uc | 48V ac |
| Contactor Application | Motor Control, Resistive Load |
| Pole and Throw Configuration | 3 |
| Ue Rated Voltage Power circuit | 690 V AC 50/60 Hz, Signalling circuit |
Key Features
- Compact design allows DIN rail mounting and panel installation.
- Equipped with 3 normally open contacts and 1 normally closed auxiliary contact.
- Rated for motor control and resistive load applications with pre-wired reversing circuit.
- Includes mechanical interlock and screw terminal connections for secure wiring.
- Suitable for operating temperatures from -25°C to 50°C.
- Complies with multiple standards including IEC, UL, CSA, CCC, and RoHS.
- Constructed for disassembly as part of sustainable product design.
- Manufactured in France with global certification for industrial and automation uses.
Product Description
Schneider Electric LC2K0601E7 is a high-quality, compact 3-pole TeSys K Reversing Contactor engineered for motor control and resistive load applications. It features a 48V AC coil compatible with 50/60Hz power supply, capable of controlling motors up to 2.2kW at 400V or 4kW at 690V AC. The contactor includes three normally open (3 NO) power poles and one normally closed (1 NC) auxiliary contact, facilitating reliable reversing control.
This device is designed for easy integration into industrial control panels with DIN rail mounting and screw clamp terminals ensuring firm electrical connections. It incorporates a mechanical interlock and a pre-wired reversing circuit to prevent simultaneous activation of forward and reverse contacts, enhancing safety and functionality.
The contactor operates efficiently within an ambient temperature range of -25°C to 50°C, making it suitable for various industrial environments. It meets rigorous international standards such as IEC, UL, CSA, CCC, EAC, and compliant with RoHS directives, highlighting its quality and safety credentials.
Manufactured in France, the LC2K0601E7 is a part of Schneider Electric's commitment to sustainability, featuring design for disassembly to support recycling and reuse. Its compact 90mm width optimizes panel space without compromising performance.
Applications include motor control, reversing operations, and resistive load switching in industrial automation, manufacturing plants, HVAC systems, water treatment, and other commercial environments requiring reliable electrical switching devices.
Compact 3-pole design with mechanical interlock and reversing circuit included. 48V AC coil voltage supporting 50/60Hz operation frequency. 6A current rating with power capability of up to 4kW at 690V AC. One normally closed auxiliary contact (1 NC) built-in for control signaling.
Suitable for DIN rail mounting using screw terminals for reliable connectivity. Complies with international safety and environmental standards. Operating temperature range from -25°C to 50°C for versatile deployment. Certified Green Premium product supporting sustainability goals.
Explore Schneider Electric products and related automation control gear at EnvMart for trusted industrial automation solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a power rating of 4kW at 690V AC.
The coil voltage for this unit is 48V AC.
The dimensions are 90mm in width, 58mm in length, and 57mm in depth.
It can operate at a maximum temperature of 50°C.
This reversing contactor features 3 poles.
It is designed for DIN rail mounting.
It includes one normally closed (1 NC) auxiliary contact.
It complies with IEC, UL, CSA, CCC, and RoHS standards.
The operational current rating is 6A.
It is suitable for motor control, resistive load applications, and reversing operations.
The normal state configuration consists of 3 normally open (3 NO) contacts.
This reversing contactor is manufactured in France.
