Schneider Electric LC2K Reversing Contactor, 230V AC Coil, 3-Pole, 9 A, 4 kW, 3 NO, 690V AC LC2K0901U7
Specifications
| Country of Origin | France |
|---|---|
| Brand | Schneider Electric |
| Function | Motor Control, Reversing |
| Length | 58mm |
| Model | LC2K0901U7 |
| Depth | 57mm |
| Width | 90mm |
| Mount Type | DIN Rail |
| Series | LC2K |
| Power Rating | 4kW |
| Maximum Operating Temperature | 50°C |
| Minimum Operating Temperature | -25°C |
| Terminal type | Screw |
| Number of Poles | 3 |
| Standards/Approvals | UL, CSA |
| Contact Voltage | 690V ac |
| Coil Voltage | 230V ac |
| Normal State Configuration | 3 NO |
| Better World Claim | Designed for Disassembly |
| Contact Current | 9A |
| Number of Auxiliary Contacts | 1 |
| Auxiliary Contact Configuration | 1 NC |
| Operational Current Ie | 9A |
| Control Circuit Voltage Uc | 230V ac |
| Contactor Application | Resistive Load, Motor Control |
| Pole and Throw Configuration | 3 |
| Ue Rated Voltage Power circuit | 690 V AC 50/60 Hz, Signalling circuit |
Key Features
- Equipped with a 230V AC coil voltage for precise control.
- Features 3 poles with a contact voltage rating of 690V AC.
- Supports a contact current of 9 Amperes and power rating of 4 kW at 230V AC.
- Normal state configuration includes 3 normally open (NO) contacts and 1 normally closed (NC) auxiliary contact.
- Designed for mounting on DIN rails for easy installation.
- Constructed with screw terminals for reliable connection.
- Operates within a temperature range of -25°C to 50°C, ensuring durability.
- Compliant with UL and CSA standards for safety and quality.
Product Description
Schneider Electric LC2K0901U7 Reversing Contactor is a high-quality motor control device featuring a 230V AC coil and designed primarily for motor control and resistive load applications. It is a 3-pole contactor equipped with a 9 Amp operational current and a power rating of 4 kW at 230V AC. This product is part of the LC2K series and complies with UL and CSA standards to ensure reliable performance.
The contactor comes pre-assembled with a reversing power busbar and features 3 normally open (NO) contacts along with 1 auxiliary normally closed (NC) contact, enhancing its versatility in control circuits. It is designed for mounting on DIN rails, providing ease of installation in industrial electrical panels.
The device uses screw-type terminals for secure wiring and supports a control circuit voltage of 230V AC. Its operational temperature range is from -25°C to 50°C, suitable for varied industrial environments. The contactor is rated for a contact voltage of 690V AC and is suited for AC-4, AC-3, and AC-1 categories of operation, making it ideal for motor reversing and other industrial automation functions.
The product is designed with environmental sustainability in mind, featuring a design for disassembly to support recycling and reuse. Manufactured in France, this reversing contactor is a durable and high-performance solution for industrial automation, electrical control, and motor operation tasks.
Equipped with a 230V AC coil for efficient motor control. Three poles with 9A current rating support robust electrical demand. Includes 3 NO main contacts and 1 NC auxiliary contact for flexible circuit control. DIN rail mount type ensures easy and secure installation in control panels.
Operates reliably from -25°C to 50°C temperature range. Meets UL and CSA standards for safety and compliance. Designed for disassembly, supporting environmental sustainability. Constructed with screw terminal connections for dependable wiring.
Manufactured in France with high-quality standards.
This Reversing Contactor is ideal for industrial, manufacturing, HVAC, and automation system applications where reversing motor control and reliable switching are critical. Schneider Electric's LC2K series delivers performance combined with robust safety features. Explore EnvMart's broad range of Schneider Electric automation components for comprehensive solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The coil voltage of this reversing contactor is 230V AC.
The maximum contact current for the LC2K0901U7 is 9 Amperes.
It has a power rating of 4 kW at 230V AC.
This reversing contactor features 3 poles.
The contact voltage rating is 690V AC.
It is designed for mounting on DIN rails, which facilitates easy installation.
The operational temperature range is from -25°C to 50°C.
The LC2K0901U7 includes 3 normally open (NO) contacts.
Yes, it has 1 normally closed (NC) auxiliary contact.
It complies with UL and CSA standards for safety and quality.
The depth is 57mm and the width is 90mm.
It is designed for motor control and reversing applications.
