Schneider Electric Reversing Contactor 3-Pole 6A 4kW 230V AC Coil LC2K0601P7
Specifications
| Country of Origin | India |
|---|---|
| Brand | Schneider Electric |
| Function | Motor Control, Resistive Load, Reversing |
| Length | 58mm |
| Model | LC2K0601P7 |
| Depth | 57mm |
| Width | 90mm |
| Mount Type | Plate, Rail Mount |
| Series | LC2K |
| Power Rating | 4kW |
| Maximum Operating Temperature | 50°C |
| Minimum Operating Temperature | -25°C |
| Terminal type | Screw Clamp |
| Number of Poles | 3 |
| Standards/Approvals | CCC, CSA, EAC, IEC, RoHS, UL |
| Contact Voltage | 690V ac |
| Coil Voltage | 230V ac |
| Normal State Configuration | 3 NO |
| Better World Claim | Designed for Disassembly |
| Contact Current | 6A |
| Number of Auxiliary Contacts | 1 |
| Auxiliary Contact Configuration | 1 NC |
| Operational Current Ie | 6A |
| Control Circuit Voltage Uc | 230V ac |
| Contactor Application | Motor Control |
| Pole and Throw Configuration | 3 |
Key Features
- Operates efficiently at a coil voltage of 230V AC.
- Supports 3 poles with a 6A contact current and 4 kW power rating.
- Features 3 normally open (NO) main contacts and 1 normally closed (NC) auxiliary contact.
- Suitable for motor control, resistive load, and reversing applications.
- Mechanical interlock prevents simultaneous forward and reverse closing.
- Mounts easily on plate or rail for flexible installation.
- Designed to operate reliably between -25°C and 50°C with an altitude tolerance up to 2000 meters.
- Provides secure screw clamp terminals suitable for 0.34 to 4 mm² conductors.
Product Description
Schneider Electric LC2K0601P7 Reversing Contactor is a compact motor control device designed for reversing three-phase motors and managing control circuits in industrial electrical setups. It operates with a 230V AC coil voltage and handles up to 6A of contact current, making it ideal for controlling small to moderate industrial motors with a power rating of 4 kW.
This contactor features a 3-pole configuration with 3 normally open main contacts and 1 normally closed auxiliary contact for interlocking and signalling purposes. Its mechanical interlock mechanism prevents simultaneous forward and reverse activations, enhancing operational safety.
Mounting is versatile with plate and rail options, allowing easy integration into various control panels or DIN-rail mounted enclosures. The device is equipped with screw clamp terminals that securely accommodate conductor sizes from 0.34 to 4 mm².
Engineered to withstand environmental challenges, it operates reliably across a temperature range of -25 °C to 50 °C and up to altitudes of 2000 meters without requiring derating. The contactor complies with strict international standards including CCC, CSA, EAC, IEC, RoHS, and UL, ensuring dependable performance and safety.
Its electrical endurance is robust with a mechanical rating of up to 5 million cycles and electrical durability of 1.3 million cycles at 6A AC-3, suitable for demanding industrial applications. The coil inrush power consumption is 30 VA with a hold-in power of 4.5 VA at 20 °C.
Typical applications include reversing conveyor and belt-drive motors, forward/reverse control of pump motors, small machine tool motor direction control, and automated material-handling systems. Fuse recommendations support up to 25A gG for power circuits at voltages ≤ 440V.
Operates at 230V AC coil voltage for precise motor control. Three poles with 6A current rating accommodate small motors efficiently. Mechanical interlock ensures safe reversing operation. Mountable on rail or plate for flexible installation.
Certified to multiple international standards for reliability. This product supports sustainable industrial practices under RS Better World initiatives and is designed for disassembly, promoting environmental responsibility.
Explore more Schneider Electric automation products and contactors on EnvMart for industrial and commercial applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The power rating of this model is 4 kW.
It has a maximum contact current of 6A.
This reversing contactor operates at a coil voltage of 230V AC.
It features a 3-pole configuration.
The dimensions are 58mm in length, 57mm in depth, and 90mm in width.
It is equipped with screw clamp terminals suitable for conductor sizes from 0.34 to 4 mm².
It operates reliably between -25°C and 50°C.
It is suitable for motor control, resistive load, and reversing applications.
It has a mechanical interlock that prevents simultaneous forward and reverse closing.
It can be mounted easily on either a plate or rail, allowing for flexible installation.
It complies with several international standards including CCC, CSA, EAC, IEC, RoHS, and UL.
It has an electrical durability of 1.3 million cycles at 6A AC-3.
