TRACOPOWER PIANO Switched Mode DIN Rail Power Supply 230V AC Input 28V DC, 5A Output, 120W PIC120.242C
Specifications
| Country of Origin | China |
|---|---|
| Brand | TRACOPOWER |
| Power | 120W |
| Efficiency | 90.5% |
| Height | 124mm |
| Model | PIC120.242C |
| Depth | 124mm |
| IP Rating | IP20 |
| Width | 124mm |
| Series | PIANO |
| Output Current | 5A |
| Maximum Operating Temperature | 70°C |
| Sub Type | Switched Mode |
| Minimum Operating Temperature | -10°C |
| Number of outputs | 1 |
| Maximum Input Voltage | 230V ac |
| Electrical Phase | 1 |
| Maximum Output Voltage | 28V dc |
| Minimum Input Voltage | 180V ac |
Key Features
- Supports single-phase AC input voltage from 180V to 230V for stable operation.
- Compact design with dimensions 124mm x 124mm x 124mm suitable for DIN rail mounting.
- High efficiency of 90.5% reduces energy consumption and heat generation.
- Wide operating temperature range of -10°C to 70°C ensures durability in harsh environments.
- Equipped with screw terminals for secure electrical connections.
- Produces low ripple factor and noise with 100mVpp output quality.
- Conforms to multiple certification standards including UL, CE, FCC, and VDE for safety and EMC compliance.
- IP20 rated enclosure provides protection in typical industrial settings.
Product Description
PULS PIC120.242C Switched Mode DIN Rail Power Supply is engineered for reliable industrial power distribution, supporting a 230V AC input and delivering 28V DC output with 5A current at 120W power rating. This power supply integrates a single-phase design with high efficiency and robust construction.
The unit features a light and compact housing measuring 124mm in width, depth, and height, facilitating easy DIN rail installation in control panels and automation systems. Its design ensures high service lifetime and stable operation across a wide temperature range from -10°C to 70°C.
Performance characteristics include an efficiency rating of up to 90.5%, low ripple and noise levels of 100mVpp, and large input/output terminals connected via screw terminals for secure and maintenance-friendly wiring. The output voltage is adjustable between 24VDC and 28VDC, optimized for diverse industrial equipment and automation devices.
The power supply complies with international standards including EN 61000-4-x series for electromagnetic compatibility, UL 60950-1 and UL 508 certifications for safety, CE marking, FCC compliance, VDE standards, and others, reflecting its suitability for industrial control, communication, and instrumentation equipment.
Applications primarily include industrial control cabinets, automation systems, communication equipment, and instrumentation devices requiring stable DC power. The device's light yet durable housing ensures ruggedness and reliable performance in demanding environments.
Supports single-phase AC input voltage from 180V to 230V for stable operation. Compact design with dimensions 124mm x 124mm x 124mm suitable for DIN rail mounting. High efficiency of 90.5% reduces energy consumption and heat generation.
Wide operating temperature range of -10°C to 70°C ensures durability in harsh environments. Equipped with screw terminals for secure electrical connections. Produces low ripple factor and noise with 100mVpp output quality.
Conforms to multiple certification standards including UL, CE, FCC, and VDE for safety and EMC compliance. IP20 rated enclosure provides protection in typical industrial settings. Explore the PULS DIN Rail Power Supplies category on EnvMart for more high-performance industrial power solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The output voltage of this power supply is adjustable between 24V DC and 28V DC.
It provides a maximum output current of 5A.
This unit has a compact design with dimensions of 124mm x 124mm x 124mm.
It has an efficiency rating of up to 90.5%, which helps reduce energy consumption and heat generation.
It supports a single-phase AC input voltage range from 180V to 230V.
The operating temperature range is from -10°C to 70°C, allowing for use in various environments.
It features an IP20 rated enclosure, providing protection suitable for typical industrial settings.
It is equipped with screw terminals for secure electrical connections, facilitating maintenance-friendly wiring.
It conforms to multiple certification standards including UL, CE, FCC, and VDE for safety and EMC compliance.
This model is primarily used in industrial control cabinets, automation systems, communication equipment, and instrumentation devices.
It produces a low ripple factor and noise level of 100mVpp, ensuring good output quality.
The TRACOPOWER PIANO power supply is manufactured in China.
