TE Connectivity AMPMODU MOD I Series Straight Through Hole PCB Header, 12 Contacts, 3.96 mm Pitch, 1 Row, Shrouded 280614-2
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 750V |
| Brand | TE Connectivity |
| Orientation | Straight |
| Current | 3A |
| Model | 280614-2 |
| Mount Type | Through Hole |
| Housing Material | Glass Filled Polycarbonate |
| Contact Material | Brass |
| Series | AMPMODU MOD I |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -65°C |
| Number of Rows | 1 |
| Pitch | 3.96mm |
| Contact Plating | Gold |
| Number of Contacts | 12 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Board-to-Board, Wire-to-Board |
| Tail Pin Length | 3.3mm |
Key Features
- Features 12 male contacts arranged in a single row with 3.96 mm pitch for compact PCB connections.
- Made with glass filled polycarbonate housing providing UL 94V-1 flame retardant protection.
- Gold-plated brass contact material ensures excellent conductivity and corrosion resistance.
- Operating temperature range from -65°C to 105°C suitable for harsh environments.
- Supports a voltage rating of 750 V and current rating of 3 A per contact.
- Shrouded design with polarization prevents mismating and protects pins from damage.
- Suitable for board-to-board and wire-to-board connections using through-hole mount style.
- Tail pin length of 3.3 mm facilitates secure solder termination.
Product Description
TE Connectivity 280614-2 AMPMODU MOD I Series Straight Through Hole PCB Header is a high-quality interconnect system component. It features 12 gold-plated brass male contacts arranged in a single row with a precise 3.96 mm pitch to facilitate dense and reliable electrical connections on PCBs.
The header housing is constructed from glass filled polycarbonate material that meets UL 94V-1 flame retardant standards, ensuring safety and durability in power and industrial control applications. The shrouded design provides pin protection and polarization to prevent incorrect mating, enhancing robustness in demanding environments.
This PCB header supports a continuous current of 3 A per contact and withstands up to 750 V, making it suitable for a wide range of electronic assembly applications including power supplies, industrial control equipment, and switchgear systems.
Designed for through-hole mounting, the connector offers secure solder termination with a 3.3 mm tail pin length. Its operating temperature range from -65°C to 105°C enables reliable performance under varied thermal conditions.
Features 12 male contacts arranged in a single row with 3.96 mm pitch for compact PCB connections. Glass filled polycarbonate housing rated UL 94V-1 for flame retardancy and safety. Gold-plated brass contacts for reliable conductivity and corrosion resistance.
Operates safely between -65°C and 105°C for industrial and commercial environments. 750 V voltage rating and 3 A current capacity per contact ensure electrical performance. Shrouded and polarized design prevents pin damage and mismating during assembly.
Through-hole mount type facilitates robust solder joint and mechanical stability. Applicable for board-to-board and wire-to-board interconnect systems.
This AMPMODU Mod I PCB Header is part of TE Connectivity’s rugged 3.96 mm pitch interconnect system suitable for various industrial, commercial, and electronic product assemblies where durability, precise connection, and safety are required.
Explore more professional-grade PCB connectors and headers in EnvMart's Electronics Components category designed for consistent performance and reliability.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The contacts in this PCB header are arranged with a pitch of 3.96 mm.
This model has a voltage rating of 750 V.
The current rating for each contact is 3 A.
The housing is made from glass filled polycarbonate, and the contacts are made of gold-plated brass.
It operates within a temperature range of -65°C to 105°C.
This header features a total of 12 male contacts.
It supports through-hole mounting for secure installation.
The tail pin length is 3.3 mm, facilitating secure solder termination.
The shrouded design with polarization helps prevent mismating and protects the pins from damage.
It is suitable for both board-to-board and wire-to-board connections.
Yes, the housing material meets UL 94V-1 flame retardant standards.
This model is part of the AMPMODU MOD I Series.
