XP Power Switching Power Supply 24V DC 5W PCB Mount Ultra-Compact ECE05US24

XP Power ECE05US24 Switching Power Supply is a 5W PCB mount power supply designed to provide a regulated 24V DC output. This ultra-compact, encapsulated power supply unit offers high reliability and is suitable for industrial, laboratory, construction, and electrical power distribution applications. The device operates efficiently with an output power of 5 watts and features an efficiency rating of 83%, ensuring energy-conscious performance.

This power supply supports an input voltage range from 85V to 264V AC, making it compatible with universal AC power sources. It is designed for a wide operating temperature range, from -25°C to 70°C, suitable for a variety of environmental conditions. With a SMPS output current of 210mA and a single output configuration, it can reliably power sensitive electronic circuits.

The unit complies with multiple standards and approvals including EN 61000-4 series for electromagnetic compatibility, CSA22.2 No. 234 per cUL, EN 60950-1, and UL 60950-1 safety certifications, ensuring robust quality and safety compliance in demanding environments.

Physical dimensions are compact with a length and width of 25.4mm and a depth of 15.24mm, and it weighs 16 grams, making it ideal for space-restricted PCB mounting applications. Its encapsulated design provides protection against environmental factors and enhances durability.

Provides a regulated 24V DC output voltage with 5W power delivery. PCB mount type suitable for integration on compact electronic assemblies. Wide input voltage compatibility between 85V AC to 264V AC. Operating temperature range from -25°C to 70°C ensures reliability under varied conditions.

High efficiency of 83% reduces heat generation and operational costs. Meets international standards for electromagnetic compatibility and safety. Ultra-compact design with small footprint and light weight for easy installation.

Ideal for industrial, electronic, and power supply applications requiring dependable DC power.

This robust and space-efficient switching power supply from XP Power’s ECE series is engineered to provide stable power for various industrial electronics, automation equipment, and instrumentation systems. Its wide compliance with global standards makes it suitable for deployment in international markets. The encapsulated and compact form factor aligns with modern design requirements, helping designers achieve reliable power solutions in small areas.
