WEG Thermal Overload Relay RW17, 1 NO/1 NC, 1.8A F.L.C, 1.2A - 1.8A Adjustable Current, 1.4W Power Rating RW17



Category Thermal Overload Relay Brand WEG Condition New

Specifications

Country of Origin	Brazil
Brand	WEG
Length	71.5mm
Model	RW17
Depth	82.5mm
IP Rating	IP10, IP20
Width	45mm
Mount Type	DIN Rail
Series	RW17
Power Rating	1.4W
Maximum Operating Temperature	60°C
Minimum Operating Temperature	-25°C
Terminal type	Screw
Supply Voltage	100, 50V
Contact Voltage	690V ac
Reset Method	Automatic & Manual
Normal State Configuration	1 NO/1 NC
Relay Contact Current	1.2, 1.8A
Number of Auxiliary Contacts	2
Pole and Throw Configuration	3
FLC Motor Rating	1.8A
Adjustable Current Range	1.2 → 1.8 A

Key Features

Automatic and manual reset methods offer flexible operation.
Mounts easily on DIN rail for convenient installation.
Features 1 normally open and 1 normally closed contact configuration.
Rated for 1.2A to 1.8A relay contact current and 1.8A motor full load current.
Operates in temperatures from -25°C to 60°C for broad environmental use.
Equipped with IP10 and IP20 ratings for protection against dust and objects.
Suitable for applications up to 690V AC contact voltage.
Complies with IEC and EU regulations for quality and safety.

Product Description

WEG RW17 Thermal Overload Relay model RW17-1D3-D018 offers precise motor overload protection with adjustable current settings ranging from 1.2 to 1.8 amps and a power rating of 1.4 watts. This relay utilizes both automatic and manual reset methods, enabling adaptive control suitable for various industrial automation and electrical systems.

This device is designed with a 1 NO/1 NC contact configuration and rated relay contact currents at 1.2 and 1.8 amps, providing reliable operation for motor full load currents of 1.8 amps. Its compact size (45mm width, 71.5mm length, 82.5mm depth) allows it to fit seamlessly into standard DIN rail mounting setups.

The relay operates efficiently within a temperature range from -25°C to 60°C and features IP10 and IP20 ingress protection ratings ensuring resistance against dust and accidental contact, making it suitable for industrial and commercial electrical control panels.

Equipped with two auxiliary contacts, the relay supports complex control circuit functions and phase failure sensitivity with a Class 10 tripping characteristic. It complies with multiple international standards including IEC 60947-1, IEC 60947-4-1, IEC 60034-30-1, and EU Directive 2009/125/EC, confirming high reliability and compliance for safety and performance.

This relay is ideal for industrial, manufacturing, HVAC, and water treatment applications requiring dependable motor overload protection with precise current adjustment capabilities.

Automatic and manual reset methods provide operational flexibility. DIN rail mount simplifies installation in control panels. 1 NO and 1 NC contact arrangement supports versatile circuit configurations. Adjustable current range from 1.2 to 1.8 amps matches motor requirements.

Compact dimensions enable space-saving panel designs. Wide operational temperature range ensures durability in harsh environments. IP10 and IP20 ratings offer protection against dust ingress. Compliant with IEC standards and EU regulations for safety and quality.

Two auxiliary contacts enhance control circuit functionality. Manufactured in Brazil to high-quality standards.
