LKMelectronic Temperature Transmitter PT100 Input 0 to 200°C 0-10 V Output 35V Supply LKM 224/3

LKMelectronic LKM 224/3 Temperature Transmitter is designed for industrial process control and temperature measurement applications. This analogue transducer accepts PT100 sensor inputs and converts the temperature-dependent resistance signals into standardized outputs of 4 to 20 mA or 0 to 10 V, suitable for automation and monitoring systems.

The transmitter supports temperature input measurement from 0°C to 200°C, operating reliably in environments ranging from -25°C minimum ambient up to 85°C maximum ambient temperature, making it well-suited for diverse industrial settings including manufacturing, process control, HVAC systems, and laboratory instrumentation.

Its compact build with a depth of 53 mm allows installation on a standard 35 mm DIN rail, optimizing space and integration in complex control panels. The device is powered with a maximum supply voltage of 35 V, ensuring compatibility with various low voltage control systems.

Features include a range and zero-point regulator to conduct subsequent fine adjustments for high precision measurement, maintaining a temperature-linear output signal that conforms to international standards EN 61326-1:2006 and EN 61326-2-3:2006, as well as the DIN EN 60751 specification for PT100 sensors.

Produced in Germany, this new condition transmitter is engineered for dependable performance and long-term durability in industrial and laboratory automation applications. It does not carry hazardous area certification and is intended for non-hazardous zones.

Supports PT100 input signal compliant with DIN EN 60751 standards. Output voltage range from 0 to 10 V for integration with control systems. Wide operating temperature range from -25°C to 85°C ambient. Compact size and 35 mm DIN rail mount compatibility.

35 V maximum supply voltage for low-power installations. Range and zero-point regulator for precise calibration. Certified to EN 61326-1:2006 and EN 61326-2-3:2006 standards. Manufactured in Germany ensuring quality and reliability.

Explore our full selection of Temperature Transmitters to meet your industrial automation needs with assured precision and compliance.
