binder Circular Connector Subminiature Cable Plug 4 Contacts Male IP40 60V 3A 719 Series 09-9767-70-04

binder 09-9767-70-04 Circular Connector is a subminiature cable plug designed for industrial and automation settings requiring compact, reliable electrical connections.

This male connector from the 719 Series provides a straightforward straight orientation and includes four gold-plated brass contacts for enhanced signal quality and corrosion resistance. The durable polyamide housing ensures mechanical strength and is rated for operating temperatures from -25°C up to 70°C.

With a snap-in mating mechanism, this connector allows quick, tool-free assembly, making it suitable for installations in confined spaces where frequent disconnections are not required. Rated at 60 volts and a continuous current capacity of 3 amps, it supports many low-voltage signal transmission and light power distribution tasks.

The IP40 protection rating denotes suitability for indoor, dust-free environments, ensuring the connector is protected against solid objects but not against liquids.

This connector finds ideal use in sensor and actuator cabling within automation cabinets, control panels, and small machinery. It also meets the demands of compact motor controllers requiring multipin inputs and laboratory test rigs for precise signal routing.

This circular connector features a subminiature size suitable for compact industrial and automation applications. Equipped with four gold-plated brass contacts providing enhanced conductivity and corrosion resistance. Designed with solder termination ensuring secure and permanent conductor attachment.

The connector houses a durable polyamide construction capable of operating at temperatures ranging from -25°C to 70°C. The snap-in mating type offers fast, tool-free engagement and reliable retention. Rated for 3A continuous current and 60V, making it ideal for low-voltage signal and light-power applications.

IP40 protection makes it suitable for indoor environments free from dust and liquid exposure. Straight orientation with an 8 mm shell size for easy integration in tight spaces. Specifically suited for sensor and actuator cabling in automation cabinets and control panels.

Supports multi-signal or power distribution in compact motor controllers and laboratory equipment.

The connector’s robust design and reliable electrical performance make it an excellent choice for industrial, manufacturing, automation, and laboratory applications. Explore the wide range of Circular Connectors at EnvMart for efficient and secure connectivity solutions.
