STMicroelectronics 650 V 10 A Switching Schottky Diode Surface Mount TO-263 3-Pin STPSC10H065GY-TR

Free Delivery in India | Lowest Global Shipping Charges

STMicroelectronics 650 V 10 A Switching Schottky Diode Surface Mount TO-263 3-Pin STPSC10H065GY-TR

Name: STMicroelectronics 650 V 10 A Switching Schottky Diode Surface Mount TO-263 3-Pin STPSC10H065GY-TR
Brand: STMicroelectronics
SKU: 184238
Price: 4 USD
Availability: InStock



Category Semiconductor Diode Brand STMicroelectronics Condition New

Specifications

Country of Origin	India
Diameter	3.75mm
Brand	STMicroelectronics
Height	4.4mm
Length	10mm
Model	STPSC10H065GY-TR
Width	8.95mm
Mount Type	Surface
Maximum Operating Temperature	175°C
Package Type	TO-263
Minimum Operating Temperature	-40°C
Pin Count	3
Automotive Standard	AEC-Q101
Maximum Continuous Forward Current If	10A
Peak Reverse Repetitive Voltage Vrrm	650V
Diode Configuration	Single
Rectifier Type	Switching
Peak Reverse Current Ir	425μA
Peak Non-Repetitive Forward Surge Current Ifsm	470A
Maximum Forward Voltage Vf	2.5V

Key Features

Surface mount diode designed for high efficiency power conversion applications.
Automotive quality compliant with AEC-Q101 standard.
Maximum forward voltage of 2.5 V ensuring low power loss.
Wide operating temperature range from -40°C to 175°C for robust performance.
High peak non-repetitive forward surge current of 470 A improves surge handling.
Single diode configuration with switching rectifier type.
Low peak reverse current of 425 µA enhances efficiency.
Packaging in D²PAK (TO-263) form factor suitable for surface mount technology.

Product Description

The STMicroelectronics STPSC10H065GY-TR is a high-performance Silicon Carbide (SiC) Schottky diode designed for reliable switching and power rectification in industrial, automotive, and power electronics applications. Rated at 650 V peak reverse voltage and 10 A maximum continuous forward current, this diode features a switching rectifier configuration in a compact 3-pin D²PAK (TO-263) surface mount package.

This diode ensures very high efficiency with a maximum forward voltage of 2.5 V and minimal reverse recovery, making it ideal for modern power converters that demand reduced size, cost, and electromagnetic interference. Its automotive-grade qualification to AEC-Q101 standard guarantees high reliability under demanding conditions, including operation in temperatures ranging from -40°C up to 175°C.

Key physical dimensions include a length of 10 mm, width of 8.95 mm, and height of 4.4 mm, suitable for compact PCB layouts. The device withstands peak non-repetitive forward surge currents of up to 470 A, providing robustness against transient events common in power electronics stages.

Typical applications include power supplies, industrial power modules, automotive electronics, and DC-DC converters where efficient switching and low losses are critical. The diode's low peak reverse current (425 µA) further enhances its efficiency and energy savings.

Surface mount TO-263 package with 3 pins for easy integration in automated assembly processes. Automotive standard compliance (AEC-Q101) for enhanced durability and reliability. Reduced electromagnetic interference and simplified certification processes.

ECOPACK 2 compliant ensuring environmental friendliness of the component. Industry-grade silicon carbide technology offers high performance and thermal stability. Suitable for industrial, automotive, power supply, and converter applications demanding robust switching elements.

This component is part of STMicroelectronics' broad semiconductor portfolio, designed to meet the exacting standards of modern power electronics industries. EnvMart offers this reliable STPSC10H065GY-TR diode as a critical device for improving efficiency, reducing system size, and enhancing overall power system performance.

Explore more products in our Semiconductor Diode category.
