MaxLinear Programmable Transceiver 28-Pin SOIC W 5V Single Supply 10Mbps RS232 RS485 SP334CT-L

MaxLinear SP334CT-L is a programmable transceiver designed for electronic communication systems. It is housed in a compact 28-pin SOIC W package suitable for surface mounting. Operating at a nominal supply voltage of 5V and capable of handling maximum supply voltages of up to 5.5V, it achieves data rates up to 10Mbps. The transceiver supports differential signal types for robust RS232 and RS485 interface standards crucial in industrial and commercial electronic applications.

This device operates reliably within an ambient temperature range from 0°C to 70°C, making it appropriate for various operating environments. It draws a low supply current of 1.8mA, improving energy efficiency in embedded systems.

Its form factor dimensions are 17.9mm in length, 7.5mm in width, and 2.35mm in height ensuring optimal board space usage. The SP334CT-L offers enhanced electrostatic discharge protection up to ±15kV as per IEC 61000-4-2 standards and Human Body Model (HBM), safeguarding sensitive circuits.

This transceiver comprises 2 transceivers in one package allowing multi-protocol communication flexibility required in complex networking systems. The device is designed to be pin and specification compatible with popular industry standard transceivers, enabling easy drop-in replacement.

Typical use cases include industrial automation, control systems, data acquisition, and communications equipment requiring reliable RS232 and RS485 interfaces. The device features 2 transceivers facilitating multi-protocol communication.

It operates within a temperature range of 0°C to 70°C ensuring reliable performance. Packaged in a 28-pin SOIC W form factor with dimensions 17.9mm length, 7.5mm width, and 2.35mm height. Utilizes a single 5V supply voltage up to 5.5V with low supply current of 1.8mA.

Supports differential transmitter and receiver signal types for robust data transmission. Designed for surface mounting on PCBs enabling compact and efficient assembly. Offers enhanced ESD protection tolerating up to ±15kV per IEC 61000-4-2 and Human Body Model.

Pin and specification compatible with popular industry standard devices for easy integration. Explore more semiconductor and transceiver products from MaxLinear at EnvMart for reliable and efficient industrial electronics solutions.
