KEMET C4C Polypropylene Capacitor, 47 nF, ±5%, 3 kV DC, 750 V AC, Through Hole Mounting C4CAYUC2470AA1J

The KEMET C4CAYUC2470AA1J is a C4C series polypropylene film capacitor designed for demanding industrial and electronic circuit applications. Featuring a capacitance of 47 nF and a tolerance of ±5%, it supports high voltage applications with a rated DC voltage of 3 kV and AC voltage of 750 V. Its through-hole mounting and wire lead terminals make it suitable for secure PCB attachment.

This capacitor offers excellent performance with a low Equivalent Series Resistance (ESR) of 26 milliohms and a minimal dissipation factor of 0.0005%, which reduces energy loss and heat generation. The component operates reliably across a wide temperature range from -40°C to 85°C, making it suitable for industrial environments.

Encased in a plastic package measuring 44 mm in length, 19 mm in width, and 19 mm in height, the capacitor has a lead length of 6 mm and 1 mm lead diameter, ensuring robust electrical connection. The metallised polypropylene film construction provides self-healing properties and high ripple current capability, ideal for snubber circuits, electronic ballasts, and motor applications.

This capacitor series is widely used to suppress voltage peaks, clamp signals, and perform coupling or decoupling functions in power semiconductor circuits. It complies with internationally recognized standards including EN 61071, IEC 61071, and VDE 0560, ensuring quality and safety.

Manufactured with metallised polypropylene film for high reliability. Rated for 750 V AC and 3 kV DC operation. Through hole mounting with wire lead terminals. Operating temperature range from -40°C to 85°C. Low Equivalent Series Resistance (ESR) of 26 mΩ for minimal losses.

Lead length of 6 mm and lead diameter of 1 mm for secure connection. Plastic case with dimensions 44 mm length, 19 mm width, and 19 mm height. Very low dissipation factor of 0.0005% ensuring energy efficiency. Complies with standards EN 61071, IEC 61071, and VDE 0560.

This product is ideally suited for industrial, manufacturing, electronic equipment, and power control applications. EnvMart invites you to explore our comprehensive selection of high-quality Film Capacitors and other electronic components for your projects and operational needs.
