Carlingswitch DPST Latching On-None-On Rocker Switch Panel 10A 250V AC 28V DC IP68 RCV-37106210

Carlingswitch RCV-37106210 DPST Latching On-None-On Rocker Switch Panel is an industrial-grade panel-mounted switch designed for reliable electrical control in industrial, commercial, and automation applications. It features a double pole single throw (DPST) contact configuration with a latching On-None-On switch operation allowing stable and secure switching conditions. Rated for 10 amperes contact current at up to 250 volts AC and 28 volts DC, this switch is suitable for a wide range of electrical control tasks.

The switch housing is constructed from high-quality polyethylene terephthalate, ensuring durability and chemical resistance. Its panel cutout size is precisely 21.08 x 36.83 mm, allowing easy integration into control panels. The switch is equipped with quick connect terminals sized at 6.35 mm for fast and secure electrical connections.

Designed to withstand harsh environments, the switch carries an IP68 ingress protection rating when used without panel assembly, protecting against dust and water ingress. The operating temperature range spans from -40°C to +70°C, supporting demanding conditions.

The switch’s contact material is silver, providing excellent conductivity and longevity, and features a low contact resistance of 10 milliohms. It has a high mechanical endurance rating with a mechanical life of 150,000 operations, ensuring long service life in repetitive switching applications.

This switch does not come with an actuator included, allowing users to select compatible actuator types for their applications. Illuminated versions with neon, red, or green LEDs are available separately for visual status indication, although the supplied model is non-illuminated.

The switch operates with a latching On-None-On mechanism for stable switching. Polyethylene terephthalate housing assures durability and chemical resistance. Panel cutout size is 21.08 x 36.83 mm for panel integration. 10A contact current rating suitable for various electrical loads.

IP68 protection rating offers dust and water resistance. Quick connect terminals of 6.35 mm facilitate easy wiring. Operating temperature range spans -40°C to 70°C. Silver contact material ensures optimal electrical conductivity.

Mechanical life rated at 150,000 operations for longevity. Switch supplied without actuator for user customization.

Applications for this rocker switch include industrial control panels, electrical machinery, automation systems, building automation, and other commercial electrical installations requiring reliable switching solutions with robust environmental protection.

The product is manufactured in Mexico and complies with international standards including BS, CE, CSA, RoHS, UL, and VDE, highlighting its quality and safety. It is part of the Carlingswitch RCV series.
