TDK 220 nF 25V dc ±10% Multilayer Ceramic Capacitor Surface Mount 0603 Package C1608X7R1E224K080AC

Free Delivery in India | Lowest Global Shipping Charges

TDK 220 nF 25V dc ±10% Multilayer Ceramic Capacitor Surface Mount 0603 Package C1608X7R1E224K080AC



Category Multilayer Ceramic Capacitor Brand TDK Condition New

Specifications

Country of Origin	India
Voltage	25V dc
Brand	TDK
Height	0.8mm
Length	1.6mm
Model	C1608X7R1E224K080AC
Packaging	Tape & Reel
Width	0.8mm
Mount Type	Surface
Construction	Stacked
Termination Type	Solder
Maximum Operating Temperature	125°C
Tolerance	±10 %
Capacitance	220nF
Minimum Operating Temperature	-55°C
Standards/Approvals	RoHS, REACH
Package/Case	0603
Dielectric	X7R

Key Features

Constructed using stacked multilayer ceramic design for enhanced mechanical strength.
Package size is 0603 with compact dimensions of 1.6 mm length, 0.8 mm width, and 0.8 mm height.
Dielectric type X7R provides stable capacitance over operating temperature range.
Termination is solder type suitable for reliable surface mounting on PCBs.
Operates reliably between -55°C and 125°C maximum temperature.
Complies with RoHS and REACH standards for environmental safety.
Low equivalent series resistance (ESR) ensures low self-heating and high ripple resistance.
Non-polarized capacitor suitable for AC and DC applications.

Product Description

The TDK C1608X7R1E224K080AC is a 220 nF multilayer ceramic capacitor designed for surface mounting on printed circuit boards. Rated at 25V DC with ±10% tolerance, this capacitor features a compact 0603 package measuring 1.6 mm in length, 0.8 mm in width, and 0.8 mm in height. Its X7R dielectric type ensures stable performance across a wide temperature range from -55°C to 125°C, making it suitable for diverse industrial and electronic applications including power supply circuits, mobile devices, telecommunications equipment, AV electronics, and industrial robots.

The stacked multilayer construction alternates multilayer dielectrics and inner electrodes, providing superior mechanical strength and reliable performance. The capacitor's low equivalent series resistance (ESR) offers low self-heating and excellent ripple current resistance, improving circuit reliability. It features solder termination optimized for surface mount assembly, enhancing automated production efficiency.

This component complies with international environmental standards such as RoHS and REACH, ensuring it is free from hazardous substances. Stacked multilayer ceramic chip design for durability and reliability. Compact 0603 package ideal for high-density PCB layouts.

X7R dielectric supports wide temperature operating conditions. Solder termination suitable for surface mount technology (SMT). Low ESR and ESL minimizes losses and improves frequency characteristics. Non-polarized design allows usage in various AC/DC circuits.

Compliant with RoHS and REACH environmental standards.

The TDK C1608X7R1E224K080AC is widely used across electronics manufacturing industries including consumer electronics, telecommunications, computing equipment, automotive electronics, and industrial automation equipment. Its balance of capacitance value, voltage rating, and compact size makes it a versatile choice for filtering, decoupling, and signal conditioning applications.

Browse more Multilayer Ceramic Capacitors and electronic components on EnvMart for competitive options and extensive technical data.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The capacitance value of this model is 220 nF.

It is rated for 25V DC.

The dimensions of the 0603 package are 1.6 mm in length, 0.8 mm in width, and 0.8 mm in height.

This model operates reliably between -55°C and 125°C.

It uses an X7R dielectric type, which provides stable capacitance over a wide temperature range.

The termination type is solder, suitable for surface mounting on PCBs.

It complies with RoHS and REACH standards for environmental safety.

This capacitor has a low equivalent series resistance (ESR), which ensures low self-heating and high ripple resistance.

It features a stacked multilayer construction, which enhances mechanical strength and reliability.

This model is non-polarized, making it suitable for both AC and DC applications.

It is packaged in tape and reel format, optimized for automated production.

This capacitor is suitable for various applications including power supply circuits, mobile devices, telecommunications equipment, and industrial robots.
