TDK 220 nF Multilayer Ceramic Capacitor 25V DC ±10% Tolerance Surface Mount 0402 Package C1005X5R1E224K050BC

Free Delivery in India | Lowest Global Shipping Charges

TDK 220 nF Multilayer Ceramic Capacitor 25V DC ±10% Tolerance Surface Mount 0402 Package C1005X5R1E224K050BC



Category Multilayer Ceramic Capacitor Brand TDK Condition New

Specifications

Country of Origin	India
Voltage	25V dc
Brand	TDK
Height	0.5mm
Length	1mm
Model	C1005X5R1E224K050BC
Packaging	Tape & Reel
Width	0.5mm
Mount Type	Surface
Construction	Stacked
Termination Type	Solder
Maximum Operating Temperature	85°C
Tolerance	±10 %
Capacitance	220nF
Minimum Operating Temperature	-55°C
Standards/Approvals	REACH, RoHS
Package/Case	0402
Dielectric	X5R

Key Features

Compact 0402 package size ensuring minimal PCB footprint.
Constructed with stacked multilayer dielectric and inner electrodes enhancing reliability.
Dielectric type X5R suitable for temperature range -55°C to 85°C.
Terminated with solder finish for secure surface mounting.
Packaged in tape & reel format facilitating automated assembly.
Compliance with REACH and RoHS standards.
Offers low Equivalent Series Resistance (ESR) and low Equivalent Series Inductance (ESL) for superior frequency characteristics.
Designed for use in power supply circuits and general electronics including mobile devices, AV equipment, and industrial robotics.

Product Description

TDK C1005X5R1E224K050BC is a 220nF multilayer ceramic capacitor designed for surface mount applications. It features a compact 0402 case package with a rated voltage of 25V DC and a tolerance of ±10%, making it suitable for precise electronic circuitry requiring stable capacitance under typical operating conditions from -55°C to 85°C.

The capacitor utilizes a stacked construction of multilayer dielectric and inner electrodes to provide superior mechanical strength and consistent electrical performance. Its dielectric material is classified as X5R, which ensures reliable operation within its temperature and voltage ratings. The solder termination type supports secure mounting on printed circuit boards.

Packaged in tape and reel format, this capacitor facilitates efficient pick-and-place automated assembly in manufacturing environments. It complies with environmental regulations including REACH and RoHS, ensuring it meets industry standards for safe use.

Its low equivalent series resistance (ESR) and low equivalent series inductance (ESL) yield outstanding frequency characteristics, making it ideal for applications in power supply circuits, consumer electronics, telecommunication devices, automotive electronics, home appliances, and industrial robotics.

The monolithic construction ensures enhanced mechanical durability and high reliability, vital for maintaining performance in diverse industrial, commercial, and telecommunications applications.

Compact 0402 surface mount package facilitates space-saving electronic designs. Reliability engineered for use in power supplies, mobile devices, and general electronics. Compliant with environmental safety standards REACH and RoHS.

Low ESR and ESL improve ripple resistance and frequency response. High mechanical strength from stacked multilayer design. Suitable for automated assembly due to tape & reel packaging. Wide temperature operating range from -55°C to 85°C.

This capacitor is categorized under MLCCs - Multilayer Ceramic Capacitors at EnvMart, suitable for electronics manufacturers, repair technicians, and engineers requiring high-quality, reliable Multilayer Ceramic Capacitors for complex circuit designs.
