ROHM USB Controller , 22V Maximum Supply Voltage, 3.67V Minimum Supply Voltage, USB Type C, UCSP50L2 Package BD93F10MWV-E2

Free Delivery in India | Lowest Global Shipping Charges

ROHM USB Controller , 22V Maximum Supply Voltage, 3.67V Minimum Supply Voltage, USB Type C, UCSP50L2 Package BD93F10MWV-E2

Name: ROHM USB Controller , 22V Maximum Supply Voltage, 3.67V Minimum Supply Voltage, USB Type C, UCSP50L2 Package BD93F10MWV-E2
Brand: ROHM
SKU: 177317
Price: 7.83 USD
Availability: InStock



Category USB Interface IC Brand ROHM Condition New

Specifications

Country of Origin	India
Brand	ROHM
Height	570μm
Length	2.63mm
Model	BD93F10MWV-E2
Width	2.63mm
Mount Type	PCB
Maximum Operating Temperature	150°C
Package Type	UCSP50L2
Minimum Operating Temperature	-55°C
Standards/Approvals	RoHS, IEC 61000-4-2
Automotive Standard	AEC-Q101
Maximum Supply Voltage	22V
Minimum Supply Voltage	3.67V
USB Specification	USB Type C
Supported Protocols	USB

Key Features

Supports USB Power Delivery protocol via base-band communication.
Integrated 32Bit ARM Cortex-M0 processor for embedded control.
Includes VBUS N-channel MOSFET switch gate driver and VBUS discharge switch.
Features 28V protection voltage for CC pins and supports dead battery operation.
I²C interface enables host communication with embedded controllers or SoCs.
Operates reliably between -55°C to 150°C for automotive and industrial environments.
Complies with RoHS and IEC 61000-4-2 standards for safety and electromagnetic compatibility.
Equipped with AEC-Q101 automotive standard certification for quality assurance.

Product Description

ROHM BD93F10MWV-E2 USB Controller is a high-voltage USB Type-C power controller supporting USB Power Delivery protocol version 3.0 and USB Type-C specification version 1.3. It is engineered for seamless integration with embedded controllers or SoCs via an I²C interface, ideal for industrial, automotive, and consumer electronics requiring robust USB power management.

This device features an integrated 32-bit ARM Cortex-M0 processor, enabling advanced policy engine functions and control logic directly on the chip. The controller includes built-in VBUS N-channel MOSFET switch gate driver and VBUS discharge switch, enhancing power management and protection capabilities.

Designed with a compact UCSP50L2 surface mount package, the controller's small footprint (2.63mm length and width, 570μm height) facilitates integration into compact PCB layouts. It supports a minimum supply voltage of 3.67V and a maximum of 22V, making it versatile for various USB power configurations.

The BD93F10MWV-E2 protects CC pins with up to 28V and supports dead battery operation, ensuring safe and reliable operation in diverse scenarios. It is rated for a wide operating temperature range from -55°C to 150°C, and adheres to automotive quality standards including the AEC-Q101 certification.

RoHS compliant and meeting IEC 61000-4-2 standards, this USB controller guarantees electromagnetic compatibility and environmental safety. It is perfect for use in industrial machines, automotive electronics, and high-performance consumer applications where efficient and reliable USB power control is critical.

Supports USB Power Delivery and USB Type-C specifications. Embedded 32-bit ARM Cortex-M0 processor for enhanced control. Integrated VBUS switch gate driver and discharge switch. 28V CC pin protection and dead battery support.

I²C host communication interface. RoHS compliant and IEC 61000-4-2 standard certified. AEC-Q101 automotive standard qualified. This makes the ROHM BD93F10MWV-E2 a highly reliable and compact solution for USB power control in industrial, automotive, and consumer electronics environments.
