Amphenol Communications Solutions Bergstik Series Vertical Through Hole Pin Header, 7 Contacts, 2.54 mm 77311-118-07LF

Amphenol Communications Solutions 77311-118-07LF Bergstik Series vertical through hole pin header is engineered for reliable board-to-board interconnections in various electronic equipment and devices. It offers a 7-contact configuration with a 2.54 mm pitch and is designed for high voltage and current applications, rated at 1500V and 3A respectively.

The header utilizes a high temperature thermoplastic housing that facilitates reflow compatibility and mechanical stability. Its unshrouded male contacts are crafted from phosphor bronze material with matching plating to ensure excellent conductivity and corrosion resistance. This component is suited for mezzanine applications, allowing mating either from the top or bottom, thus enabling flexible stacking and varied height configurations.

The pin header supports through hole mounting with solder termination providing robust mechanical and electrical connections on printed circuit boards. Operating temperature capabilities range from -65°C to 130°C, making it suitable for demanding industrial, laboratory, and commercial electronic environments.

These headers are UL approved under the standard E66906, confirming their compliance with strict safety and performance requirements. The design includes a 3.05 mm tail pin length and a 5.84 mm mating pin length to maintain secure and precise engagement with mating connectors.

Manufactured in France, this high-quality PCB Pin Header is ideal for applications requiring durable and reliable interconnect systems, including communications, industrial automation, and electronic manufacturing sectors.

High temperature thermoplastic housing material ensures durability. Rated for 1500V voltage and 3 ampere current capacity. Unshrouded male contact design suitable for mezzanine and flexible stacking applications. Vertical orientation with solder termination and through hole mount type.

Phosphor bronze contacts and plating provide reliable conductivity. Operating temperature range from -65°C to 130°C. UL Approval E66906 for industry compliance. Mating pin length of 5.84 mm and tail pin length of 3.05 mm.
