Infineon PFC Controller Evaluation Board with Integrated IR11688S Controller and 2EDF7275F Driver KITACTBRD60R065S7TOBO1
Specifications
| Country of Origin | Slovenia |
|---|---|
| Brand | Infineon |
| Model | KITACTBRD60R065S7TOBO1 |
| For Use With | Power Supplies |
| Standards/Approvals | RoHS |
| Kit Classification | Evaluation Board |
| Featured Device | Integrated IR11688S Controller and 2EDF7275F Driver, 600 V CoolMOSTM S7 |
| Kit Name | KIT_ACT_BRD_60R065S7 |
Key Features
- The evaluation board replaces standard diode bridge rectifiers with an active full-bridge for line rectification in CCM boost PFC applications.
- Designed primarily for power supplies and telecom sectors ensuring high efficiency.
- Extremely compact design suitable for space-constrained integration.
- Features integrated power factor correction controller and drivers for optimized operation.
- Complies with RoHS standards for environmental safety and compliance.
- Kit name is KIT_ACT_BRD_60R065S7 with reliable evaluation board functionality.
- Country of origin is Slovenia, ensuring quality manufacturing standards.
Product Description
Infineon KITACTBRD60R065S7TOBO1 is a PFC controller evaluation board featuring an integrated IR11688S controller and 2EDF7275F driver based on 600 V CoolMOSTM S7 technology. This evaluation board is designed to replace traditional diode bridge rectifiers with an active full-bridge for line rectification in continuous conduction mode (CCM) boost power factor correction (PFC) applications. The compact and highly efficient board is primarily targeted for use in power supply designs and telecommunications equipment.
This board improves efficiency in power conversion by integrating advanced controller and driver ICs optimized for high-voltage switching. Its compact footprint facilitates easy incorporation into development and testing environments. The kit is identified by the model KIT_ACT_BRD_60R065S7 and has earned RoHS compliance, reflecting adherence to environmental and safety standards.
Key technical features include seamless integration of the IR11688S controller with the 2EDF7275F driver to enable precise control of the 600 V CoolMOSTM S7 power MOSFET devices. The active full bridge configuration enhances power quality and reduces losses associated with traditional diode bridge rectifiers.
The evaluation board supports industrial and telecommunications applications requiring efficient power factor correction and robust line rectification. Its design assists engineers in prototyping and evaluating PFC circuits with advanced integrated components.
The evaluation board replaces standard diode bridge rectifiers with an active full-bridge for improved efficiency in CCM boost PFCs. The integrated IR11688S controller and 2EDF7275F driver enable precise control of 600 V CoolMOSTM S7 MOSFET devices.
Extremely compact design suitable for diverse power supply and telecommunication applications. Kit is RoHS compliant, assuring environmentally safe manufacturing practices. Designed to aid engineers in development and testing of power factor correction circuits.
Model KIT_ACT_BRD_60R065S7 facilitates accurate evaluation of power management components. Manufactured in Slovenia with adherence to quality standards. Explore the full range of Power Management Development Kits at EnvMart, providing comprehensive solutions for industrial and telecommunications power electronics design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It features an integrated IR11688S controller and a 2EDF7275F driver based on 600 V CoolMOSTM S7 technology.
The board is primarily targeted for use in power supply designs and telecommunications equipment that require efficient power factor correction.
The evaluation board complies with RoHS standards, reflecting adherence to environmental safety and compliance.
The evaluation board is manufactured in Slovenia, ensuring quality manufacturing standards.
The model name is KIT_ACT_BRD_60R065S7.
It enables precise control of 600 V CoolMOSTM S7 power MOSFET devices.
Yes, it features an extremely compact design suitable for space-constrained integration.
The kit is classified as an Evaluation Board.
