SICK Block Capacitive Proximity Sensor 6 mm Detection, PNP Output, 100 mA, 30 V DC, IP67 CQF16-06EPSEW1
Specifications
| Country of Origin | Lithuania |
|---|---|
| Brand | SICK |
| Length | 34mm |
| Output signal | 100 mA, output type and function can be selected: PNP/NPN, N/O/N/C |
| Model | CQF16-06EPSEW1 |
| Depth | 8mm |
| IP Rating | IP67 |
| Width | 16mm |
| Mount Type | Non-Flush |
| Housing Material | Plastic |
| Output type | PNP |
| Series | CQF |
| Maximum Operating Temperature | 80°C |
| Minimum Operating Temperature | -25°C |
| Switching Current | 100mA |
| Terminal type | Cable |
| Body Style | Block |
| Maximum dc Voltage | 30V dc |
| Shielding | Unshielded |
| Maximum Switching Frequency | 10Hz |
| Standards/Approvals | CE, UL |
| Maximum Supply Voltage | 30V |
| Materials Detected | Cm, Water Based Liquids Upto A Conductivity Of 50 Ms |
| Maximum Detection | 6mm |
| Food industry | Detection of food in pipes |
| Compact, rugged housing, enclosure rating | IP67, IP68, IP69K |
| Semi-conductor industry | Detection of process liquids without direct contact to the liquids |
Key Features
- Compact and rugged block-style housing suitable for various industrial applications.
- Capacitive sensor technology detects liquids and materials through container walls.
- High enclosure rating of IP67, with extended IP68 and IP69K certifications for harsh environments.
- Flexible output configuration with selectable PNP/NPN switching and normally open/closed functions.
- Two LEDs indicate voltage supply and output signal status for easy diagnostics.
- Equipped with a cable and optional M8 male connector for versatile installation.
- Operating temperature range from -25°C to 80°C ensures reliable performance in varied conditions.
- Suitable for level detection in semiconductor, food industry, and chemical processing applications.
Product Description
SICK CQF16-06EPSEW1 Block Capacitive Proximity Sensor offers reliable level detection with a compact plastic housing and robust design rated IP67, IP68, and IP69K. It operates with a maximum detection range of 6 mm and supports PNP output with a switching current capacity of 100 mA at 30 V DC supply voltage.
This sensor excels at detecting liquids and materials, including water-based liquids up to a conductivity of 50 ms/cm, both through container walls and in direct contact. The advanced measurement principle compensates for foam, moisture, and deposits ensuring accurate liquid level sensing without false signals.
The device includes dual LEDs indicating power supply and output state for quick visual diagnostics and supports flexible output configurations selectable between PNP/NPN and normally open/closed modes via a teach-in function. The supplied cable and optional M8 male connector facilitate easy integration into automation systems, while the mounting bracket supports flexible mounting options.
Operating across a temperature range of -25°C to 80°C, the CQF16-06EPSEW1 sensor is well-suited for demanding industrial environments such as semiconductor manufacturing, food processing pipelines, freezer condensate detection, toner level measurement, and adhesive container level monitoring.
Compact and robust block housing with high ingress protection suitable for harsh industrial conditions. Capacitive sensing enables detection of various liquid levels, compensating for foam and residues. Selectable output types and functions for integration flexibility in control systems.
Dual LED indicators simplify sensor status verification and troubleshooting. Mounting bracket included to support multiple installation configurations. Wide temperature and voltage operating ranges guarantee stable performance in diverse applications.
Choose the SICK CQF16-06EPSEW1 for precise, reliable capacitive proximity sensing in industrial, laboratory, food processing, and semiconductor sectors. Explore more sensors and solutions in the proximity sensor category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum detection range of the SICK CQF16-06EPSEW1 is 6 mm.
This model features a PNP output type, with selectable functions for normally open or normally closed operation.
The operating temperature range for this sensor is from -25°C to 80°C.
It can detect water-based liquids with a conductivity of up to 50 ms/cm, both through container walls and in direct contact.
The dimensions of the sensor are 34 mm in length, 16 mm in width, and 8 mm in depth.
The maximum switching frequency of the CQF16-06EPSEW1 is 10 Hz.
This model has an IP rating of IP67, with extended certifications of IP68 and IP69K for harsh environments.
The sensor supports non-flush mounting, and it comes with a mounting bracket for flexible installation options.
The maximum supply voltage for the CQF16-06EPSEW1 is 30 V DC.
Yes, it is equipped with dual LEDs that indicate the voltage supply and output signal status for easy diagnostics.
This sensor is suitable for applications in the semiconductor, food processing, and chemical processing industries.
The CQF16-06EPSEW1 complies with CE and UL standards.
