Turck Radar Level Sensor with Stainless Steel Housing and Polyetheretherketone Gasket LRS510
Specifications
| Country of Origin | Germany |
|---|---|
| Resolution | 1 mm |
| Brand | Turck |
| Model | LRS510 |
| Cable Length | 10m |
| Housing Material | Stainless Steel |
| Series | LRS510 |
| Maximum Operating Temperature | 65°C |
| Maximum Pressure | 16bar |
| Minimum Operating Temperature | -25°C |
| Maximum Current | 250mA |
| Device Type | Radar |
| Interface Type | IO-Link |
| Maximum dc Voltage | 33V dc |
| Standards/Approvals | FCC, CE, ETSI, UL |
| Gasket Material | Polyetheretherketone |
Key Features
- Radar technology enables precise distance and level detection with 1 mm resolution.
- Housing constructed from stainless steel ensures durability and resistance to harsh environments.
- Polyetheretherketone gasket offers chemical resistance and sealing reliability.
- Operates effectively across a temperature range of -25°C to 65°C.
- Supports IO-Link interface for seamless integration with industrial control systems.
- Maximum pressure tolerance is up to 16 bar suitable for challenging process conditions.
- Includes 10 m cable length enabling flexible installation options.
- Supports DC voltage up to 33 V and current up to 250 mA.
Product Description
The Turck LRS510 Radar Level Sensor, model LRS510-10-69-2UPN8-H1141, is engineered for precise level measurement in industrial applications. Featuring a robust stainless steel housing and a polyetheretherketone gasket, the sensor delivers exceptional durability and chemical resistance.
This radar sensor operates with a resolution of 1 mm and uses a cone angle of ±5°, allowing accurate detection within its 10 m range and a minimal blind zone of 35 cm. The device outputs distance, level, volume, or percentage measurements, providing versatile data formats suitable for process control and monitoring.
Designed to function reliably in temperature conditions ranging from -25°C to 65°C and pressure up to 16 bar, the sensor supports a maximum DC voltage of 33 V and current of 250 mA. The rotatable 180° housing after mounting enables customized installation orientation following the 3/4" NPT process connection.
Connection is facilitated through a 10-meter cable with IO-Link interface, ensuring easy integration into automation systems. Certified to meet FCC, CE, ETSI, and UL standards, this level radar sensor is manufactured in Germany guaranteeing stringent quality and industry compliance.
Radar technology provides accurate level measurement with 1 mm resolution. Stainless steel housing offers mechanical strength and corrosion resistance. Polyetheretherketone gasket enhances chemical sealing performance. Wide operational temperature range supports diverse environmental conditions.
IO-Link interface enables secure and flexible data communication. Pressure rating up to 16 bar allows use in rigorous process conditions. Includes 10 m cable length for installation versatility. Rotatable housing design permits optimal sensor alignment.
Industry certifications ensure adherence to safety and quality standards. Manufactured in Germany ensuring high reliability and durability.
This radar level sensor is ideal for industrial automation, water treatment plants, manufacturing process controls, and HVAC systems requiring precise liquid or material level monitoring. Its rugged design and advanced sensing capabilities support critical infrastructure applications.
Explore the full range of Turck Level Sensors and automation products at EnvMart for reliable industrial control solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Turck LRS510 sensor has a measurement resolution of 1 mm.
The maximum operating temperature for the LRS510 is 65°C.
This model can tolerate a maximum pressure of up to 16 bar.
The sensor supports an IO-Link interface for integration with industrial control systems.
The LRS510 sensor includes a cable length of 10 meters.
The operating temperature range for the Turck LRS510 is from -25°C to 65°C.
The housing is constructed from stainless steel, and the gasket is made of polyetheretherketone.
The rotatable housing allows for a 180° adjustment after mounting, enabling customized installation orientation.
The sensor is certified to meet FCC, CE, ETSI, and UL standards.
It can output distance, level, volume, or percentage measurements, providing versatile data formats.
The LRS510 supports a maximum DC voltage of 33 V and a maximum current of 250 mA.
This model is suitable for industrial automation, water treatment plants, manufacturing process controls, and HVAC systems for precise liquid or material level monitoring.
