Turck Radar Level Radar Sensor with Polyetheretherketone Gasket and Stainless Steel Housing, IO-Link Interface, 10m LRS510
Specifications
| Country of Origin | Germany |
|---|---|
| Resolution | 1 mm |
| Brand | Turck |
| Model | LRS510 |
| Cable Length | 10m |
| Housing Material | Stainless Steel |
| Series | LRS510 |
| Maximum Operating Temperature | 65°C |
| Maximum Pressure | 16bar |
| Minimum Operating Temperature | -25°C |
| Maximum Current | 250mA |
| Device Type | Radar |
| Interface Type | IO-Link |
| Maximum dc Voltage | 33V dc |
| Standards/Approvals | ETSI, FCC, UL, CE |
| Gasket Material | Polyetheretherketone |
Key Features
- Equipped with a 10 meter cable length for flexible installation.
- Housing made of durable stainless steel ensuring longevity.
- Polyetheretherketone gasket offers chemical resistance and sealing efficiency.
- Operates within -25°C to 65°C temperature range.
- Features an IO-Link interface for industrial communication.
- Supports maximum DC voltage of 33V and maximum current of 250mA.
- Pressure resistant up to 16 bar for robust operational conditions.
- Radar beam cone angle is ±5° with measurement resolution of 1 mm.
Product Description
Turck LRS510-10-57-LI2UPN8-H1141 Radar Level Radar Sensor delivers advanced level measurement using radar technology, featuring a stainless steel housing and a polyetheretherketone (PEEK) gasket for superior chemical resistance and mechanical strength. Its housing can be rotated 180° after the process connection is mounted with the NPT 3/4" fitting, enabling customizable installation to suit diverse industrial setups.
This sensor provides a maximum measurement range of 10 meters with a blind zone of 35 centimeters, offering high accuracy with a resolution of 1 mm. The radar beam has a narrow cone angle of ±5°, ensuring precise targeting and minimal interference. Equipped with an IO-Link interface, it enables seamless integration within automated industrial systems for real-time data communication.
Designed to operate in temperatures ranging from -25°C to 65°C and withstand pressures up to 16 bar, this device is ideal for demanding environments in process control, automation, and industrial instrumentation. The device supports a maximum DC voltage of 33V and maximum current of 250mA, conforming to certifications including ETSI, FCC, UL, and CE, though it has no hazardous area certification.
10 meter cable length supports flexible and extended installation. Stainless steel housing provides durability and corrosion resistance. Polyetheretherketone gasket ensures chemical resistance and sealing effectiveness. Operating temperature range from -25°C to 65°C for broad applicability.
IO-Link interface facilitates easy integration with automation systems. Maximum operating pressure up to 16 bar for tough process conditions. High accuracy with 1 mm resolution and ±5° radar cone angle. Rotatable 180° housing for installation flexibility.
Compliant with ETSI, FCC, UL, and CE standards. Made in Germany guaranteeing stringent quality control standards.
This radar level sensor is well suited for applications in industrial automation, manufacturing, process control, water treatment, and chemical processing industries where reliable level measurement is critical. The rugged construction with stainless steel housing and advanced radar technology ensures long-term performance and accuracy.
Explore more advanced Level Sensors and automation products available, all engineered for precision and reliability.
