Amphenol Limited MIL Spec Circular Connector Copper Alloy Straight 19 Contacts Female 700V Crimp Bayonet 62GB-57A14-19PN

Amphenol Limited 62GB-57A14-19PN MIL Spec Circular Connector is a high-quality electronic component engineered to meet the stringent requirements of military and industrial applications. Constructed with copper alloy contacts plated in gold, this connector ensures excellent conductivity and corrosion resistance. It is designed with a straight orientation and a bayonet mating system, providing secure and reliable engagement for critical electrical connections.

This connector is rated at 700 volts and 7.5 amperes current, supporting applications operating under demanding electrical loads. It has a shell size of 14, aligning with standard connector dimensions for broad compatibility. The termination type is crimp, allowing for strong and durable wire connections. It features 19 male contacts housed in a female connector body, ensuring proper mating configuration and functional performance.

Operating temperature ranges from -55°C to 125°C, making it suitable for harsh environments across industrial, aerospace, defense, and automotive sectors. The design complies with MIL-DTL-26482 military standards, assuring the user of its quality and reliability.

The connector supports wire sizes from 24 to 8 AWG and can handle up to 45 amperes in larger wire gauges, offering flexibility for multiple circuit designs. Its aluminium shell construction with options for brass or stainless steel provide additional mechanical strength and environmental protection. The assembly includes a neoprene insulator with an integrated rear wire sealing grommet that ensures liquid-tight connections essential in industrial and outdoor use cases.

Connector features 19 male contacts ensuring robust connectivity. Copper alloy contacts are gold plated to resist corrosion and enhance conductivity. Designed with a straight orientation and bayonet mating type for secure assembly.

Operates in temperatures ranging from -55°C up to 125°C, suitable for demanding environments. Termination type is crimp, facilitating strong and stable wire connections. Meets MIL-DTL-26482 military specification ensuring high durability and performance.

Standard connector size for compatibility with a wide range of industrial systems. Designed for use with wire gauges size 24 to 8 AWG supporting up to 45A current capacity wires. Constructed with no strain relief component, prioritizing compact and rugged design.

This MIL Spec Circular Connector is ideal for industrial electronics, power distribution, aerospace systems, military applications, and other commercial machinery requiring durable, standard connectors with high electrical performance. Its robust mechanical and electrical specifications provide confidence for critical system integrations. Explore more connectors and parts within the Mil Spec Circular Connector category on EnvMart for enhanced project solutions.
