Eaton Residual Current Circuit Breaker PXF-A Series, 16A, 1-Pole, 300 mA, Type A, 500 A Breaking 236740 PXF-16/2/03-A

Eaton 236740 PXF-16/2/03-A Residual Current Circuit Breaker PXF-A Series is engineered for precise and reliable electrical safety in residential and commercial environments. It provides full electrical circuit protection by rapidly disconnecting power during earth faults to prevent electric shocks and equipment damage. This device supports Type A earth leakage protection, suitable for systems with alternating and pulsating direct currents, operating accurately even with smooth direct residual currents up to 6 mA.

With a current rating of 16A and single-pole design, it is ideal for protecting individual circuits with the capacity to withstand instantaneously tripping faults at up to 500 A breaking capacity. The 300 mA trip sensitivity provides effective fault detection while maintaining robustness during transient conditions.

The compact 80 mm x 35 mm x 45 mm form factor fits standard DIN rail mounts and quick connect terminal types allow easy integration into existing electrical panels. The lever reset actuator facilitates straightforward manual operation after trip events.

Conformity to IEC/EN 61008 and RoHS standards assures users of quality, safety, and environmental compliance. Manufactured in Serbia, this product combines durable build quality with advanced protection features such as fault current conditioning up to 250 A, compatibility with P-Series devices, and options for auxiliary switches installation.

Designed for residential and commercial electrical systems. Type A earth leakage protection with high sensitivity. Instantaneous break time ensures rapid fault clearance. Robust 500 A breaking capacity for high-current faults.

Ergonomic lever for easy manual reset operation. Quick connect terminals streamline installation processes. Fits standard DIN rail mounting assemblies for flexible placement. Complies with IEC/EN 61008 and RoHS directives.

Produced under international standards with Serbia origin.

Suitable for industrial, commercial, building automation, and residential electrical safety applications. Eaton’s PXF-A Series RCCBs are trusted for safeguarding human life and equipment by cutting out power instantly during earth leakage events. Browse the extensive Eaton electrical safety catalog at EnvMart for compatible circuit protection solutions and related electrical components.
