Eaton PXF-A Series Residual Current Circuit Breaker, 16A, 2-Pole, 10 mA Trip Sensitivity, Type A, 500A 236726 PXF-16/2/001-A

Eaton 236726 PXF-16/2/001-A Residual Current Circuit Breaker is engineered for residential and commercial electrical safety systems. Featuring a 16A current rating and two poles, it monitors residual currents with 10 mA trip sensitivity to prevent electric shock hazards and equipment damage.

Designed with Type A tripping characteristics, it effectively detects AC and pulsating DC leakage currents. Its instantaneous break time and robust 500A breaking capacity ensure rapid interruption under fault conditions and provide robust surge tolerance.

The device mounts easily on DIN rails with secure quick connect terminals, streamlining panel integrations. Compliance with important international standards like RoHS and IEC/EN 61008 offers assurance of quality and safety. The IP20 rating guarantees user touch protection against accidental contact and protection from ingress of harmful solids over 12 mm.

The lever reset actuator enhances operational convenience, allowing easy reset after fault clearance. Its compact size (80mm height × 35mm width × 45mm depth) makes it suitable for tight electrical enclosures without compromising functionality or safety.

This Residual Current Circuit Breaker is essential for applications requiring reliable earth leakage protection in both commercial and residential environments, safeguarding electrical installations, machinery, and users from current leakage risks.

The device offers 2-pole protection suitable for simultaneous circuit monitoring. Trip sensitivity of 10 mA ensures rapid disconnection in case of residual current leakage. Breaking capacity rated at 500A enables withstanding short-circuit surges effectively.

Mounting on DIN rail with quick connect terminals allows easy installation in electrical panels. Complies with RoHS and IEC/EN 61008 standards ensuring reliable performance. IP20 rated for touch protection and resistance to ingress of solid objects over 12mm.

Lever type reset actuator facilitates straightforward device resetting after tripping. Compact dimensions of 80mm height, 35mm width, and 45mm depth optimize space utilization.
