Samtec CLE Series Vertical Surface PCB Socket, 40-Contact, 2 Row, 0.8 mm Pitch, Solder Termination CLE-120-01-G-DV-A
Specifications
| Country of Origin | India |
|---|---|
| Brand | Samtec |
| Orientation | Vertical |
| Current | 2.7A |
| Model | CLE-120-01-G-DV-A |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Beryllium Copper Alloy |
| Series | CLE |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Board-to-Board |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 0.8mm |
| Standards/Approvals | RoHS |
| Contact Plating | Gold |
| Number of Contacts | 40 |
| Connector System | Board-to-Board |
| Row Pitch | 1.2mm |
| Insulator Material | black liquid crystal polymer |
Key Features
- Features a cost-effective micro socket design with Tiger Beam contact system.
- Compatible with vertical board-to-board connector systems.
- Constructed with black liquid crystal polymer housing material ensuring durability.
- Contacts made from beryllium copper alloy with gold plating for reliable electrical performance.
- Current rating of 2.7 A per contact suitable for moderate power applications.
- Designed for operating temperatures from -55°C to 125°C.
- Row pitch measures 1.2 mm, enabling compact circuit layouts.
- Complies with RoHS standards ensuring environmental safety.
Product Description
Samtec CLE-120-01-G-DV-A is a vertical surface PCB socket from the CLE series specifically designed for board-to-board connections requiring precision and reliability. This socket includes 40 contacts arranged in 2 rows, with a pitch of 0.8 mm, and is intended for solder termination, providing robust electrical connections on printed circuit boards.
The housing is manufactured from black liquid crystal polymer, which offers excellent mechanical and thermal properties suitable for industrial and commercial electronics use. The contacts employ a beryllium copper alloy with gold plating, enhancing conductivity and corrosion resistance. This socket supports a current rating of 2.7 amperes per pin, making it suitable for applications with moderate power requirements.
Operating temperature ranges from -55°C to 125°C accommodate harsh environmental conditions, ensuring device stability and performance. The 1.2 mm row pitch allows for compact placement within electronic assemblies supporting vertical orientation. Fully RoHS compliant, this product meets essential environmental directives.
This PCB socket is especially useful in industrial, manufacturing, and electronic assembly environments requiring dependable pass-through connections. It offers a cost-effective and high-quality solution to meet rigorous connection demands.
Cost-effective micro socket with Tiger Beam contact technology. 40 contacts in 2 rows with 0.8 mm pitch. Black liquid crystal polymer housing for durability. Beryllium copper alloy contacts plated with gold. 2.7 A current per contact rating.
Temperature rating from -55°C to 125°C. Row pitch of 1.2 mm for compact designs. RoHS compliance for environmental safety. Suitable for industrial and commercial PCB applications. Explore EnvMart’s extensive catalog of PCB Sockets and electronic connectors for compatible components and industry-grade solutions designed to enhance your electronic assemblies.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The current rating of this PCB socket is 2.7 A per contact, making it suitable for moderate power applications.
This model operates within a temperature range of -55°C to 125°C, accommodating harsh environmental conditions.
The socket features 40 contacts arranged in 2 rows.
The housing is made from black liquid crystal polymer, while the contacts are constructed from beryllium copper alloy with gold plating.
The pitch of this socket is 0.8 mm, allowing for compact circuit layouts.
Yes, this model complies with RoHS standards, ensuring it meets essential environmental safety directives.
This socket utilizes solder termination for robust electrical connections on printed circuit boards.
The orientation of this socket is vertical, designed for board-to-board connections.
The row pitch measures 1.2 mm, which supports compact placement within electronic assemblies.
This model is designed for surface mounting on printed circuit boards.
This PCB socket is suitable for industrial, manufacturing, and electronic assembly environments requiring dependable pass-through connections.
The country of origin for this socket is India.
