SMC Solenoid Pilot Valve 3/4 NC Single Solenoid Metric Port Size M3 x 0.5 24V Resin Body SY100

SMC SY114-5MOZ-Q is a solenoid pilot valve from the SY100 Series designed for pneumatic applications requiring precise fluid control. This 3/4 normally closed (NC) single solenoid valve operates at 24V DC and features a resin body for durability and corrosion resistance. The valve is constructed with a metric port size M3 x 0.5 and a female port gender, adhering to metric thread standards.

Engineered for industrial pneumatic systems, it supports a maximum operating pressure of 0.7 MPa and a maximum pilot pressure of 0.7 MPa. The valve offers a maximum flow rate of 11.78 L/min, making it effective for medium flow pneumatic controls. The valve function includes 3 ports and 4 positions, making it versatile in controlling airflow.

This valve is fitted with a rubber seal for enhanced sealing performance and uses a base mount type for secure installation. The electrical connection is facilitated by an M-Plug connector, offering reliable communication with the control system. It consumes a low power of 0.5 Watts, making it energy efficient during operation.

With compact dimensions - height 27.8 mm, length 34.5 mm, and width 15.5 mm - it is suitable for integration in tight spaces. It is rated for ambient and fluid temperatures up to 50°C, with a minimum operating temperature of -10°C, supporting use in varying environmental conditions. The valve features a quick response time of 10 milliseconds or less and an extensive cycle life expectancy of 100 million cycles as per SMC life testing standards.

The solenoid coil supports multiple rated voltages including 3, 5, 6, 12, and 24V DC, and several AC voltages but this specific model operates at 24V DC. It carries CE standards approval, confirming compliance with applicable European safety requirements.

Commonly used in pneumatic fluid control, manufacturing automation, industrial machinery, and HVAC systems, this valve offers reliability and precision in controlling airflow with solenoid actuation. It is suitable for laboratories, industrial automation, and process control environments requiring stringent valve performance.

Choose SMC SY114-5MOZ-Q solenoid pilot valve for efficient, long-lasting pneumatic valve performance in your pneumatic system applications. Operates at maximum pressure of 0.7 MPa with a maximum flow rate of 11.78 L/min.

Features a 3-port, 4-position valve function with female port gender and metric thread standard. Equipped with a rubber seal for secure operation and base-type mounting. Electrical connection via M-Plug connector and power consumption of 0.5 W for efficient control.

Compact dimensions with height 27.8 mm, length 34.5 mm, and width 15.5 mm suitable for pneumatic systems. Designed for ambient and fluid temperatures up to 50°C, with a minimum operating temperature of -10°C. High durability with a cycle life of 100 million cycles and a response time of 10 ms or less.
