NXP 8-bit S08 HCS08 Microcontroller, 40 MHz, 63.28kB FLASH, 2kB RAM, 44-Pin LQFP MC9S08AW60CFGE

Free Delivery in India | Lowest Global Shipping Charges

NXP 8-bit S08 HCS08 Microcontroller, 40 MHz, 63.28kB FLASH, 2kB RAM, 44-Pin LQFP MC9S08AW60CFGE



Category Microcontroller Brand NXP Condition New

Specifications

Country of Origin	India
Brand	NXP
Height	1.4mm
Length	10mm
Model	MC9S08AW60CFGE
Width	10mm
Mount Type	Surface
Series	HCS08
Maximum Operating Temperature	85°C
Package Type	LQFP
Minimum Operating Temperature	-40°C
Ram size	2kB
Interface Type	SPI, SCI
Pin Count	44
Automotive Standard	AEC-Q100
Maximum Supply Voltage	5.5V
Minimum Supply Voltage	2.7V
Device Core	S08
Program Memory Size	63.28kB
Maximum Clock Frequency	40MHz
Number of Programmable I/Os	34
Number of Timers	6
Instruction Set Architecture	CISC
ADCs	8 x 10 Bit
Program Memory Type	FLASH

Key Features

Equipped with 2kB RAM for efficient data management.
Supports SPI and SCI interfaces for flexible connectivity.
Operates within a supply voltage range of 2.7V to 5.5V.
Includes 8 analog-to-digital converters with 10-bit resolution.
Wide operating temperature range from -40°C to 85°C ensures industrial reliability.
Has 34 programmable I/O pins for versatile application requirements.
Complies with automotive standard AEC-Q100 for quality assurance.
Compact dimensions of 10mm x 10mm x 1.4mm for space-constrained designs.

Product Description

The NXP MC9S08AW60CFGE is a robust 8-bit S08 series microcontroller from the HCS08 family, optimized for high-performance embedded applications. It operates at a maximum clock frequency of 40 MHz and integrates 63.28kB of FLASH memory coupled with 2kB of RAM to support complex firmware and data requirements.

This surface-mount device comes in a 44-pin LQFP package, measuring 10mm in length and width and 1.4mm in height, enabling compact design solutions suitable for space-constrained environments.

The microcontroller supports SPI and SCI communication interfaces providing flexible serial communication options for various industrial and commercial applications. It can operate within a voltage range from 2.7V to 5.5V, making it adaptable to diverse power supply configurations.

Its 34 programmable I/Os, 6 timers, and 8 x 10-bit ADC channels make it ideal for precise control and signal processing tasks. The device complies with automotive industry standard AEC-Q100, guaranteeing reliability in harsh environments.

Featuring a CISC instruction set architecture and flash type program memory, the MC9S08AW60CFGE ensures efficient instruction execution and fast memory operations that benefit embedded system developers.

Equipped with 2kB RAM for efficient data management. Supports flexible SPI and SCI serial interfaces. Wide supply voltage range from 2.7V to 5.5V accommodates various power sources. Includes 8 x 10-bit ADC channels for accurate analog signal conversion.

Operating temperature range from -40°C to 85°C for industrial-grade reliability. Compact 44-pin LQFP package measuring 10mm x 10mm x 1.4mm. Compliant with automotive AEC-Q100 standard for quality and durability. Contains 6 timers for precise timing operations.

CISC instruction set enables effective processing capabilities. Utilizes FLASH program memory supporting reprogramming and updates.

This microcontroller is suitable for industrial, automotive, consumer electronics, and embedded system applications requiring low power consumption and high processing speed. Its comprehensive features and compact footprint make it ideal for advanced control systems and communication modules.

Explore the range of NXP Microcontrollers in our Electronics & Electricals category at EnvMart for reliable and advanced semiconductor solutions tailored to engineering and industrial needs.
