Electromen OY DC Motor Controller 5-6 V DC, 10 mA Current, Potentiometer Function EM-A1

Electromen OY EM-A1 is an auxiliary DC motor controller designed for symmetrical speed and direction control using potentiometer input with a supply voltage between 5 V and 6 V DC. It operates with a low current consumption of 10 mA, making it suitable for precise control applications.

This compact control card measures 20 mm in length and 18 mm in width, allowing easy integration into existing Electromen driver setups. It changes the control mode from unipolar to symmetric bipolar plus/minus control, enabling versatile usage with various Electromen motor controllers that feature the compatible header socket.

The EM-A1 offers an input impedance of 1 Mohm and supports input voltage ranges from -5 V to +5 V. A dead zone of ±20 mV ensures a stop area for refined control, and it supplies a negative voltage output of -5 V (up to 5 mA) to power potentiometers. The controller operates reliably in a wide temperature range from -40°C to 70°C, suitable for diverse industrial environments.

This product is ideal for industrial, automation, and electrical control applications where symmetric speed and direction motor control with potentiometer function is required. The card is compatible with Electromen drive models such as EM-151A, EM-176A, EM-206, and EM-282.

Designed for symmetrical plus/minus speed and direction control with potentiometer input. Operates at supply voltages of 5-6 V DC with maximum current consumption of 10 mA. Input impedance rated at 1 Mohm with input voltage range of -5 V to +5 V.

Supports dead zone of ±20 mV ensuring precise stopping behavior. Negative voltage supply output of -5 V at up to 5 mA for potentiometer operation. Operating temperature range from -40°C to 70°C suitable for industrial environments.

Compact dimensions measuring 20 mm length and 18 mm width. Auxiliary plug-in control card compatible with specified Electromen driver products. Enables conversion from unipolar to symmetric bipolar control for Electromen drives.

Country of origin: Finland.

This Electromen OY EM-A1 DC Motor Controller provides a reliable solution for industrial motor speed and direction control tasks. Suitable for integration in automation systems and electrical control gear, it ensures efficient and precise motor operation. Explore more Motor Controllers and electrical components in the Motors & Pumps category on EnvMart.
