ITW Switches 59 Series Miniature Push Button Switch Momentary Panel Mount SPST Clear LED IP67 125 V 59-213

The ITW Switches 59-213 miniature push button switch by ITW Switches is a momentary SPST switch designed for panel mounting with a precise 13.6 mm cutout size. It features a clear LED and is fully sealed to IP67 standards, providing total protection against dust ingress and temporary immersion in water, making it ideal for harsh industrial and military environments.

This robust switch operates reliably within a temperature range of -55°C to 125°C. It supports contact voltages up to 125 V AC/DC with a maximum contact current of 400 mA, featuring gold contacts to ensure excellent corrosion resistance and durability.

The actuator is green and square with a momentary on-off configuration, making it well-suited for use in communication equipment, instrumentation, mass transport controls, and environmentally demanding keypads. The terminal type is solder, ensuring strong and secure connections during assembly.

Manufactured with either non-spark zinc alloy or polybutylene terephthalate (PBT) body materials, the switch provides options for applications requiring spark resistance or mechanical robustness. Compliance with CSA and UL standards guarantees industry-accepted safety and quality.

This push button switch is widely used in industrial, military, laboratory, and mass transport control applications where a dependable, sealed, and rugged push button is necessary. Its miniature design allows integration into compact control panels.

The switch features a green square actuator designed for momentary on-off operation. It is panel sealed for protection against dust and temporary immersion, meeting IP67 standards. The contacts use gold for reliable performance and support up to 125 V AC/DC voltage.

Operating temperature ranges from -55°C to 125°C for versatile industrial applications. The terminal type is solder, ensuring secure electrical connections. The switch is compliant with CSA and UL standards for quality assurance.

It is suitable for communications, military, instrumentation, and mass transport control systems requiring rugged switches. The body material offers options in non-spark zinc alloy or hard-wearing polybutylene terephthalate (PBT).

Designed for industrial and environmentally demanding keypad applications. Explore more high-quality switches and components in the Electronics & Electricals category at EnvMart for your industrial and commercial needs.
