Norcomp 9 Way Straight 2.77 mm Pitch Through Hole D-Sub Connector with 4-40 Board Lock Female 171-009-213R911

Norcomp 171-009-213R911 is a 9 Way Straight 2.77 mm Pitch Through Hole D-Sub Connector with 4-40 Board Lock Female, widely used in power and electronic connector applications. This connector features stamped, gold flash plated female contacts made of brass for excellent electrical performance and durability.

The connector shell is made of steel with nickel plating, providing robustness and reliable grounding with its indented design. The insulator is glass-filled thermoplastic rated for 260°C process temperature, ensuring stability under soldering conditions.

Designed for through-hole mounting with a straight orientation, it securely mounts using 4-40 board lock hardware. It supports a maximum current of 5A and voltage up to 500V, operating efficiently within a temperature range of -50°C to 100°C.

The 2.77 mm pitch and D shell size conform to industry standard D-Sub dimensions, making it compatible for use in various electrical, industrial, laboratory, construction, HVAC, manufacturing, and computing equipment. Its robust build and gold flash plating ensure reliable contacts even in demanding environments.

Features 9 contacts enabling versatile connectivity options. Designed with a straight orientation ideal for through-hole PCB mounting. Constructed with a steel nickel-plated shell and glass-filled thermoplastic insulator.

Rated for 5A current and 500V voltage applications. Operating temperature range from -50°C to 100°C supports various environments. Contacts are brass with gold flash plating for corrosion resistance and reliable conductivity.

Mounting hardware uses 4-40 board lock for secure attachment. Pitch between contacts is 2.77 mm complying with standard D-Sub dimensions. Suitable for industrial, electronic, computing, and power connector applications. Manufactured in Taiwan, Province Of China, ensuring quality standards.

This connector is ideal for high performance, reliable electronic applications where secure through hole mountings are required. Browse more power and D-Sub Connectors on EnvMart for your industrial and electronic component needs.
