Toshiba 8 Power Switch IC SSOP 18-Pin 1.47W, Surface Mount TBD62783AFNG(Z)
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Toshiba |
| Package | PG type P-DIP18-300-2.54-001 |
| Model | TBD62783AFNG(Z) |
| Mount Type | Surface |
| Number of inputs | 8 |
| Series | TBD62783A |
| Power Rating | 1.47W |
| Maximum Operating Temperature | 85°C |
| Package Type | SSOP |
| Minimum Operating Temperature | -40°C |
| Operating Current | 100μA |
| Number of outputs | 8 |
| Pin Count | 18 |
| Maximum Supply Voltage | 25V |
| Minimum Supply Voltage | 2V |
| Switch On Resistance RdsOn | 3.25Ω |
| Input voltage(output on) | 2.0 V (MIN) |
| Input voltage(output off) | 0.6 V (MAX) |
Key Features
- Implements 8 DMOS transistor circuits with built-in clamp diodes for inductive load switching.
- Supports a maximum output voltage of 50 V and maximum output current of -500 mA per channel.
- Minimum supply voltage is 2 V with operating current of 100 μA.
- Operating temperature range from -40°C to 85°C ensures robust performance.
- Designed with a surface mount SSOP package type with 18 pins.
- Input voltage for output ON is minimum 2.0 V; output OFF voltage maximum is 0.6 V.
- Low Switch On Resistance RdsOn of 3.25Ω for efficient power switching.
- Suitable for electronic component applications requiring power management ICs.
Product Description
Toshiba TBD62783AFNG(Z) is a specialized Power Switch IC designed for electronic and electrical applications requiring robust power management solutions. Featuring 8 internal DMOS transistor circuits, it integrates clamp diodes for safely switching inductive loads in a surface mount SSOP 18-pin package configuration.
The device supports a high output voltage of up to 50 V and a continuous maximum output current of -500 mA per channel, making it well-suited for controlling multiple outputs in power management systems. It operates efficiently with a power rating of 1.47 W and a low Switch On Resistance (RdsOn) of 3.25Ω, enhancing energy efficiency and reducing losses.
With a wide operating temperature range from -40°C to 85°C, this IC is built for durability in varied industrial and commercial environments. Its minimum supply voltage of 2 V and low operating current of 100 μA ensures low power consumption during operation.
The input voltage thresholds are precisely defined, with a minimum input voltage of 2.0 V for output activation and a maximum of 0.6 V for output deactivation, optimizing control logic compatibility.
This power switch IC is ideal for diverse industrial applications including circuit switching, power control in robotics, automation systems, HVAC control panels, and other manufacturing electronics requiring reliable multi-output switching.
Implements 8 DMOS transistor circuits with built-in clamp diodes for inductive load switching. Supports a maximum output voltage of 50 V and maximum output current of -500 mA per channel. Minimum supply voltage of 2 V with very low operating current of 100 μA.
Wide operating temperature range from -40°C to 85°C. Encapsulated in a surface mount SSOP 18-pin package for compact PCB designs. Input voltage for output ON is 2.0 V minimum; output OFF voltage is 0.6 V maximum. Low switch on resistance RdsOn of 3.25Ω enhances efficiency.
Country of origin: Japan. Product condition: New. For more Power Switch ICs and related power management devices, explore EnvMart's comprehensive electronics and electricals catalog.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum output voltage supported by this model is 50 V.
It implements 8 DMOS transistor circuits.
The operating temperature range is from -40°C to 85°C.
The minimum supply voltage required for this model is 2 V.
The switch on resistance (RdsOn) is 3.25Ω, enhancing efficiency in power switching.
The maximum output current per channel is -500 mA.
It is designed in a surface mount SSOP package type with 18 pins.
The minimum input voltage required to turn the output ON is 2.0 V.
The maximum input voltage for turning the output OFF is 0.6 V.
The power rating of this model is 1.47 W.
It is suitable for applications such as circuit switching, power control in robotics, and HVAC control panels.
The country of origin for this product is Japan.
