Littelfuse Uni-Directional 1-Element TVS Diode 5 kW, 33.3 V Breakdown, 2-Pin P600 5KP30A

Littelfuse 5KP30A is a high-performance 1-element uni-directional TVS diode designed to protect sensitive electronic equipment against voltage transients caused by lightning and other transient voltage events. It provides 5 kW peak pulse power dissipation, making it suitable for demanding industrial and electronic applications requiring robust surge protection.

This diode features a single element configuration with a minimum breakdown voltage of 33.3 V and a maximum reverse stand-off voltage of 30 V, ensuring effective suppression of voltage spikes. The device is housed in a through-hole P600 package with two pins, measuring 9.1 mm in length and diameter, facilitating easy PCB mounting.

With a fast response time of less than 1 picosecond from 0 volts to breakdown voltage minimum, it offers excellent clamping capability and low incremental surge resistance. The device operates reliably over a wide temperature range from -55°C to 175°C, supporting applications in industrial, laboratory, and electronic manufacturing environments.

The diode is glass passivated for enhanced junction stability, and the matte tin lead-free plating supports environmental standards. Its low reverse leakage current of 2 microamperes ensures efficient operation with minimal energy loss. This product is halogen-free and guarantees high-temperature soldering at 265°C for 10 seconds with lead tension of 2.3 kg.

5 kW peak pulse power dissipation provides robust overvoltage protection. Uni-directional single element offers precise transient voltage suppression. Operates from -55°C up to 175°C, suitable for harsh environments. Through-hole mount and P600 package for reliable installation.

Fast response time and low leakage current enhance circuit reliability. Halogen-free and lead-free plating for ecological compliance. Glass passivated junction enhances device longevity and stability. Ideal for protection of power and electronic components in industrial setups.

Compact size with 9.1 mm length and diameter enables space-saving design. High peak pulse current rating supports exposure to extreme transient surges.

This Littelfuse 5KP30A TVS diode is widely used in protecting sensitive circuits in industrial electronics, power supply systems, automotive electronics, and communication equipment. Its robust construction and high power capability make it indispensable for ensuring equipment safety under transient voltage disturbances. Discover more quality TVS Diodes and semiconductor components at EnvMart for your next project.
