Isocom AC Input Optocoupler Through Hole 6-Pin DIP MOC8101X
Specifications
| Country of Origin | Thailand |
|---|---|
| Brand | Isocom |
| Model | MOC8101X |
| Packaging | Tape & Reel |
| Mount Type | Through Hole |
| Series | MOC |
| Maximum Operating Temperature | 100°C |
| Package Type | DIP |
| Minimum Operating Temperature | -55°C |
| Maximum input current | 60mA |
| Number Of Channels | 1 |
| Standards/Approvals | EN60950 (Nemko P01102464), CECC 00802, UL (E91231), VDE 0884 |
| Maximum Forward Voltage | 1.5V |
| Number of Pins | 6 |
| Input Current Type | AC |
| Typical Rise Time | 2μs |
Key Features
- Features a through-hole mount type for secure PCB fitting.
- Maximum forward voltage of 1.5V ensures efficient operation.
- Supports a maximum input current up to 60mA for robust performance.
- Operates reliably between -55°C and 100°C temperature range.
- Complies with standards including EN60950, CECC 00802, UL, and VDE 0884 for safety and quality assurance.
- Offers a typical rise and fall time of 2μs enabling fast switching.
- Packaged in tape & reel format for automated assembly processes.
- Comes with a single channel and standard 6-pin DIP package type.
Product Description
Isocom MOC8101X is a high-quality AC input optocoupler designed with a Gallium Arsenide infrared emitting diode optically coupled to a monolithic silicon photo transistor. Packaged in a through-hole 6-pin DIP, it ensures secure mounting on circuit boards.
This optocoupler provides excellent noise immunity and a guaranteed isolation voltage of 3750 Vac(rms), making it ideal for switchmode power supplies and other electronic applications requiring precise current transfer ratios and linearity. The internal base-to-pin 6 connection is eliminated to enhance noise resistance further.
Technical features include a maximum forward voltage of 1.5V, maximum input current of 60mA, and operating temperature range from -55°C to 100°C. Typical rise and fall times are both 2μs, delivering rapid response in signal isolation and transfer.
The component is compliant with multiple international safety standards such as EN60950, CECC 00802, UL, and VDE 0884, ensuring dependable operation in industrial, commercial, HVAC, and manufacturing environments.
Packaged in tape & reel, the MOC8101X supports efficient automated assembly lines and provides a reliable solution for optocoupler requirements across various electronic designs. Features a through-hole mount type for secure PCB fitting.
Maximum forward voltage of 1.5V ensures efficient operation. Supports up to 60mA maximum input current. Wide operating temperature range (-55°C to 100°C) for diverse environments. Compliance with EN60950, CECC 00802, UL, and VDE 0884 standards.
Typical rise and fall times of 2μs enable fast switching performance. Single channel configuration in a 6-pin DIP package. Packaged in tape & reel for industrial assembly suitability.
This Isocom Optocoupler is suitable for electronics manufacturing, power supply isolation, instrumentation, and automation applications requiring reliable signal isolation and noise immunity. Explore more optoelectronic components and related products available at EnvMart for professional industrial use.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum input current for this model is 60mA, allowing for robust performance in various applications.
It operates reliably between -55°C and 100°C, making it suitable for diverse environments.
The typical rise and fall times for this unit are both 2μs, enabling fast switching performance.
It is packaged in tape & reel format, which supports efficient automated assembly processes.
This optocoupler complies with several standards, including EN60950, CECC 00802, UL, and VDE 0884, ensuring safety and quality assurance.
The maximum forward voltage for this model is 1.5V, ensuring efficient operation.
This model features a single channel configuration, suitable for various signal isolation applications.
It features a through-hole mount type, ensuring secure fitting on printed circuit boards (PCBs).
The package type is a standard 6-pin DIP, which is commonly used in electronic applications.
The MOC8101X is manufactured in Thailand.
This unit supports AC input current, making it suitable for various electronic applications.
It is suitable for applications such as power supply isolation, instrumentation, and automation that require reliable signal isolation.
